AFL OFI-400HP Optical Fiber Identifier for High Power

The AFL Noyes OFI-400HP Optical Fiber Identifier is used to identify fibers without disrupting service. High power fiber identifier will detect power signal levels +33 to -40 dBm (@1550nm, 3mm fiber). A build-in power meter is calibrated for 3mm jacketed SMF-28. A 2-position plunger allows it to be used with 2mm jacketed fiber as well. Optical fiber identifier will detect traffic, CW and 270, 330, 1000 and 2000Hz tones. If power levels rise above 23dBm a warning message illuminates the LDC display.

The OFI-400HP fiber identifier comes with batteries, user guide and soft carry case.

The OFI-400HP Optical Fiber Identifier is designed to locate and measure the power levels of optical signals on single mode optical fiber without disrupting the integrity of the fiber. To use this device, simply clamp it onto a fiber and it will analyze the activity within the fiber.

This tester is meant to be used specifically in situations where high levels of optical power impede testing such as testing fibers with higher power level signals. If the optical power level in a fiber exceeds 500 mW, the fiber identifier will alert the user. When used in conjunction with Noyes optical light sources, the versatility of the applications greatly increases, forming a compact testing set that does not require the user to switch between testing plungers. This device is powered by 1.5 V AAA batteries, and is designed to be energy efficient, it can make thousands of fiber tests before needing battery replacement.
