T-DMP40-F01 - 40-Actuator Piezo Deformable Mirror, Tip-Tilt Actuation,

T-DMP40-F01 - 40-Actuator Piezo Deformable Mirror, Tip-Tilt Actuation, UV-Enhanced Aluminum, 8-32 and 1/4"-20 Taps

Fosco Connect Part No.: T-DMP40-F01

$ 5,520.00 or

T-DMP40-F01 - 40-Actuator Piezo Deformable Mirror, Tip-Tilt Actuation, UV-Enhanced Aluminum, 8-32 and 1/4"-20 Taps

Product Drawing

Damage Threshold Specifications^a
Item # Suffix	Laser Type	Damage Threshold
-F01	CW^b	1 W/cm (250 nm - 450 nm)
-F01	Pulsed	0.2 J/cm² (355 nm, 10 ns, 10 Hz, Ø0.38 mm)
-P01	CW^b	4 W/cm (450 nm - 2 µm)
-P01	Pulsed	1 J/cm² (1064 nm, 10 ns, 10 Hz, Ø10 mm)

a. Please note that the damage threshold is affected by the thin, flexible design of the mirror and is lower than the damage threshold for our other mirrors that use standard UV-enhanced aluminum or protected silver coating.
b. The power density of your beam should be calculated in terms of W/cm. For an explanation of why the linear power density provides the best metric for long pulse and CW sources, please see the "Continuous Wave and Long-Pulse Lasers" section below.

Damage Threshold Data for our Piezoelectric Deformable Mirrors

The specifications to the right apply to Piezoelectric Deformable Mirrors. Please note that the damage threshold is affected by the thin, flexible design of the mirrors and is lower than the damage threshold for our other mirrors that use standard metallic coatings.
