TH-S145C - Integrating Sphere Photodiode Power Sensor, InGaAs, 800 - 1700 nm, 3 W

Aperture Size  Ø12 mm

Wavelength Range 800 - 1700 nm

Power Range 1 µW - 3 W

Detector Type InGaAs Photodiode

Linearity ±0.5%

Resolution^b  1 nW

Measurement Uncertainty^c ±5%

Integrating Sphere Material (Size) Zenith^® PTFE (Ø2")

Head Temperature Measurement NTC Thermistor 4.7 kΩ

Housing Dimensions 70 mm x 74 mm x 70 mm

Active Detector Area Ø2 mm

Cable Length 1.5 m

Mounting Thread Separate 8-32 and M4 Taps, Posts Not Included

Aperture Thread Included Adapter with SM1 (1.035"-40) External Thread
