TH-S9FC1082P - Booster Optical Amplifier, 1600 - 1650 nm, Polarization Maintaining

Product Drawing

Amplifier Type BOA

Center Wavelength 1625 nm

Optical 3 dB Bandwidth 80 nm

Saturation Output Power @ -3 dB 13 dBm

Signal Gain @ P_in = -20 dBm 18 dB

Laser Class 1M

• Center Wavelength: 1050, 1300, 1550, 1590, or 1625 nm
• Typical Noise: <0.5%
• Saturation Output Powers from 9 dBm to 15 dBm
• FC/APC Input and Output Connections
• Analog Modulation Input (0 to 5 V)
• Polarization Insensitive and Polarization Maintaining Versions
• TEC Temperature Stabilized to <0.01 °C
• USB Interface for Remote Operation

BOA vs. SOA
A booster optical amplifier (BOA) is a polarization sensitive device that only amplifies light with a specific polarization. Our BOAs are pigtailed with PM fiber and will amplify light aligned to the slow axis of the input fiber connector. Our benchtop BOAs are available with center wavelengths at 1050, 1300, 1550, 1590, and 1625 nm. For amplication at 1550 nm, we also offer a semiconductor optical amplifier (SOA) that provides polarization-insensitive amplification at a lower maximum gain than the BOA counterpart.
