24-Position Fiber Optic Splice Tray (Starfighter Style, Aluminum Construction)

This 24-position fiber optic splice tray is designed for high-density splice organization and secure fiber routing within splice closures and fiber distribution systems. The tray supports fusion, mechanical, and mass ribbon splicing while maintaining proper fiber bend radius and structured cable management.

The tray is equipped with a full set of organizers to support both single and mass fusion splicing. Fiber bundle entry points are located on both ends of the tray, allowing for in-line or butt configurations and accommodating ribbon fiber, transition tubes, or jacketed fibers. An all-aluminum base and lid provide strength and long-term durability, with a black powder-coated finish suitable for demanding network environments. The tray is designed to meet Telecordia GR-769 requirements for splice organizer assemblies.

Download product spec sheet (PDF)

Specifications

• Holds up to 24 fusion splices

• Also supports 16 mechanical splices or 8 mass ribbon (12-fiber) splices

• Compatible with 40 mm or 60 mm splice protection sleeves

• Supports ribbon fiber, transition tubes, and jacketed fibers

• Dual-ended fiber entry for in-line or butt configurations

• Maintains minimum fiber bend radius

• Base material: Aluminum

• Cover material: Aluminum

• Finish: Black powder coat

• Dimensions: 7.75" L x 6" W x 0.5" H

• Weight: Approx. 0.54 lb

• Designed for installation in compatible splice enclosures

• Compliant with Telecordia GR-769 standards
