FS-S3410-24TF-P, 24-Port Ethernet L2+ PoE+ Switch, 24 x PoE+ Ports @370W, with 4 x 1Gb SFP Uplinks, Stackable Switch, Broadcom Chip

FS-S3410-24TF-P 24-Port managed PoE+ switch is equipped with 24x 10/100/1000BASE-T ports and 4x 1Gb SFP uplinks. 24x RJ45 ports support both IEEE 802.3af PoE and IEEE 802.3at PoE+ (up to 30W per port) for powering attached IP phones, wireless access points, or other standards-compliant PoE and PoE+ end network devices. It supports 4 Units of virtual stacking.

This managed enterprise switch delivers 128 Gbps switching capacity and 96 Mpps forwarding rate. It is packed with a single power supply and a single smart fan for superior processing performance and network reliability. Secure and simple access for users and loT with our Airware Cloud.

This access switch delivers a compact, cost-effective solution for campus networks, SMBs and enterprise networks.

Specifications

• Ports: 24x 10/100/1000BASE-T | 4x 1G SFP

• PoE Standard: IEEE 802.3af/at

• Switch Chip: BCM56150

• Stacking: Support

• Switching Capacity: 128 Gbps

• Input Voltage: 100-240VAC, 50-60Hz

• Forwarding Rate: 96 Mpps

• Number of VLANs: 4K

• Power Budget (Dual-power): 370W

• MAC Address: 16K

• Flash Memory: 256MB

• Jumbo Frame: 9K

• Packet Buffer: 1.5MB

• Operating Temperature: 0 to 50ºC (32 to 122°F)

• Power Supply: 1 Built-in

• Storage Temperature: -40 to 70ºC (-40 to 158°F)

• Fan Number: 1 Built-in

• Dimensions (HxWxD): 1.73''x17.32''x10.24'' (44×440×260mm)

• Airflow: Left/Right-to-Back

• Mounting Options: Desktop or Rackmount or Wall-mount

• Max. Power Consumption: 40W (460W with PoE)
• Up to 24 PoE+ Ports, Total Budget 370W

• Broadcom BCM56150 Chip, Support 4 Units Stacking

• Intelligent Fan Speed Reduction to Reduce Power Consumption and Noise

• Support DHCP, Voice VLAN, LACP, RIP, OSPFv3, etc.

• Support SSH, ACL, AAA, 802.1X, RADIUS, TACACS+, etc. for Security

• Support Airware Cloud/WEB/CLI/SNMP/SSH for Flexible Operation

Please Note: Matching the American standard power cord as default. If you need other standard power cords, please note in the order.

Software Spotlights

High Availability and Multi-Service Support

• Support stacking links
• Support line-rate IPv4/IPv6 dual-stack multi-layer switching
• Support STP/RSTP/MSTP
• Support the Rapid Link Detection Protocol (RLDP)
• Support the Ethernet Ring Protection Switching (ERPS)
• Support Rapid Ethernet Uplink Protection Protocol (REUP)

Error-Free Network Configuration

• Support Syslog, Web-based management, Telnet, SSH
• Support RMON
• Support IPv4/IPv6/MAC/ARP ACL
• Support LLDP (802.1ab)
• Support sFlow
• Support SNMP V1/V2/V3

Secure and Simplified Access for Users and IoT

• Support ARP spoofing prevention
• Support actively defending against various DDoS attacks
• Support hardware CPU protection mechanism
• Support Network Foundation Protection Policy (NFPP)
• Support DHCP snooping
• Support 802.1p, IP ToS, traffic filtering, SP, WRR

Connectivity Solutions

Cloud Platform Enables Unified Management of Branch Networks

Airware unifies the management of network devices, suitable for industries that have branches, like hotel chains, retail chains, company branches, university branches, etc.

24-Port Gigabit Fully Managed Switch with 4x 1G SFP
24× PoE+ access ports can transfer data and power a variety of devices, 4× 1 Gbps SFP slots enable high-bandwidth connectivity and non-blocking switching capacity.

Manage up to 4 Switches with a Single IP Address
Virtual stacking of up to 4 units for a total of 96 1G ports, and interconnected switches can be managed as a single device, reducing the overall number of units to monitor and manage.

370W Power Budget Powers More Devices
24× 802.3at/af-compliant PoE+ ports with a total power supply of 370W, reduce the need for separate power supplies and costs.

Voice VLAN Gives Priority to Guaranteeing VoIP Quality
Voice VLAN makes VoIP do not have to contend with all the broadcasts and other traffic from the data VLAN, ensuring it is transmitted preferentially, reducing packet loss and latency.

DHCP Accelerates Network Deployment
DHCP dynamically allocates IP addresses, simplifies IP address management, it saves more management time and costs and is more secure.

SNMP Simplifies Management and Monitors Failures
SNMP provides unified interfaces and protocols to manage devices in different physical spaces to improve management efficiency.

Comprehensive Security Policy Protects from Network Threats
With network-level security and stability capabilities like SSH, ACL, AAA, etc., it defends against network threats for enterprises, campus and financial industry.

Cloud-based Network
Configuration and debugging online optimized remotely with Airware and Airbox network.
