Signamax Media Converter SC Singlemode 10/100/1000BaseT/TX to 1000 Base SXED 10km 110V

• Extremely low latency supports larger multi-hop networks
• Extremely high reliability; MTBF of over 112 years
• Gigabit transmission supports 9K bytes jumbo frames
• IEEE 802.3x flow control for full-duplex and backpressure for half-duplex supported
• DIP switch configuration for link fault signaling, fiber auto/force mode, and SFP speed
• Full wire-speed forwarding rate
• Supports wall mounting, DIN-rail mounting, or use with media converter rack mount chassis

The Signamax 10/100/1000 to 1000 SX/LX Switching Media Converters provide an intelligent solution for long-distance connections between legacy 10BaseT and 100BaseTX networks and 1000Base Gigabit Ethernet networks. The built-in switch enables the fiber cable connection to operate at 1000 Mbps connected to either a 10BaseT, 100BaseTX, or a 1000BaseT network, while remaining completely 1000BaseSX or 1000BaseLX standard-compliant for the fiber optic connection. The fiber connection can also operate in full-duplex mode whether the RJ-45 port is connected to a full-duplex switch or a half-duplex legacy hub.

Improvements in this series of media converters include: extremely low latency, the ability to force the RJ-45 port to 100Base or 10Base full or half-duplex modes, provide auto-negotiation on the 1000Base fiber port or forced full-duplex mode where required, and the enabling or disabling of the Link Fault Signaling feature
