Fast Ethernet Standlone Coverters, 100Base-TX, RJ45 to 100Base-Fx, 1300nm, multimode, SC, 2 km

Transition Networks Part No.: E-100BTX-FX-05-SC

  • $ 295.00 or



Highlights
  • Transition Networks' 100BASE-TX to 100BASE-FX Media Converter is available in both stand-alone and slide-in-module form factors; making cost-effective integration of twisted pair and fiber optics in fast Ethernet networks easier than ever before.
  • Extend network Distance in Full-Duplex Networks
  • Used in pairs, this media converter can extend distances between two twisted pair switches or a switch and a server
  • up to 2,000 meters over multimode fiber, or up to 80,000 meters over single mode fiber.
Abstract
  • Transition Networks E-100BTX-FX-05(SC) Fast Ethernet media converter connects 100Base-TX shielded or unshielded twisted-pair copper cable to 100Base-FX fiber-optic cable.
  • Used in pairs, this media converter can extend distances between two twisted pair switches or a switch and a server up to 2 km over multimode fiber.
Product Specifications
  • Product Name 100BTX to 100BFX Standalone SC
  • Product Type Transceiver/Media Converter
  • Ethernet Technology Fast Ethernet
  • Number of Network (RJ-45) Ports 1
  • Network (RJ-45) Yes
  • Number of SC Ports 1
  • Media Type Supported Twisted Pair
  • Fiber
  • Fiber Mode Supported Multi-mode
  • Total Number of Ports 2
  • Height 1.0"
  • Width 3.0"
  • Depth 4.7"
  • Form Factor Wall Mountable
  • Network Technology 100Base-TX
  • 100Base-FX
  • Maximum Distance Supported 1.24 Mile
  • SC Port Type Duplex
  • Compatibility E-MCR-04 : 12-Slot Media Converter Rack
  • Additional Information
  • Link Pass Through
  • Automatic Link Restoration
  • Operates under heavy traffic loads without excess heat, so there is no need for a failure-prone internal fan
  • Limited Warranty Lifetime
