TH-P2-405B-PCSMA-1 - Single Mode Patch Cable, 405 - 532 nm, FC/PC to SMA, Ø3 mm Jacket, 1 m Long

TH-P2-405B-PCSMA-1 - Single Mode Patch Cable, 405 - 532 nm, FC/PC to SMA, Ø3 mm Jacket, 1 m Long

Product Drawing

• Single Mode Fiber Optic Adapter Cables for Signal Transmission from 305 nm to 2300 nm
• FC/PC to FC/APC or FC/PC to SMA Connector Options
• Narrow Key FC/PC and FC/APC Connectors
• Ø900 µm or Ø3 mm Jackets
• Custom Cables Offered
• Fiber Type SM400
• Operating Wavelength 405 - 532 nm
• Cutoff Wavelength 305 - 400 nm
• Mode Field Diameter 2.5 - 3.4 µm @ 480 nm

• Cladding Diameter 125 ± 1.0 µm
• Max Attenuation^a  ≤30 dB/km @ 532 nm
• NA 0.12 - 0.14
• Furcation Tubing Ø3 mm Yellow PVC
