T-YB1200-10/125DC-PM - Ytterbium-Doped PM LMA Double-Clad Fiber, 10 µm Core Diameter, Unit Pricing Per Meter
Roll over image to zoom in Click on image to zoom
T-YB1200-10/125DC-PM - Ytterbium-Doped PM LMA Double-Clad Fiber, 10 µm Core Diameter, Unit Pricing Per Meter

T-YB1200-10/125DC-PM - Ytterbium-Doped PM LMA Double-Clad Fiber, 10 µm Core Diameter, Unit Pricing Per Meter

Fosco ConnectSKU: T-YB1200-10-125DC-PM
Price:
$ 248.00
Silicon Valley Based
Expert Support Since 2001
Fast CA or NY Shipping

T-YB1200-10-125DC-PM - Ytterbium-Doped PM LMA Double-Clad Fiber, 10 µm Core Diameter, Unit Pricing Per Meter

Product Spec Sheet

  • Ytterbium-Doped Silica Fiber for ~1000 nm to 1100 nm Fiber Lasers and Amplifiers
  • Single Mode and Large Mode Area Options Available
  • Cladding-Pumped Designs for 1 mW to >20 W Output Power in Pulsed Operation
  • Core-Pumped Single Clad Designs with High Core Pump Absorption
  • Matched SM or LMA Passive Fiber Sold Below
  • Industry-Standard Active Fiber Geometries with Ø125 or Ø250 µm Cladding
  • PANDA Stress Rods for Polarization-Maintaining Operation
  • Type Large Mode Area
  • Cladding Type Double
  • Absorption @ 920 nm 1.7 ± 0.3 dB/m
  • Pump Type Cladding
  • Core Diameter 10.0 ± 1.0 μm
  • Cladding Diameter 125 ± 1 μm
