TH-P3-780Y-FC-5 - Single Mode Patch Cable, 780 - 970 nm, FC/APC, Ø900 µm Jacket, 5 m Long

TH-P3-780Y-FC-5 - Single Mode Patch Cable, 780 - 970 nm, FC/APC, Ø900 µm Jacket, 5 m Long

Fiber Type 780HP

Operating Wavelength 780 - 970 nm

Cutoff Wavelength 730 ± 30 nm

Mode Field Diameter 5.0 ± 0.5 µm@ 850 nm

Cladding Diameter 125 ± 1.0 µm

Coating Diameter 245 ± 15 µm

Max Attenuation^a  <3.5 dB/km @ 780 nm

NA  0.13

Connectors FC/APC, 2.0 mm Narrow Key

Jacket  Ø900 µm Yellow Hytrel^®b Tubing

Product Drawing
