TH-S146C - Integrating Sphere Photodiode Power Sensor, InGaAs, 900 - 1650 nm, 20 W

TH-S146C - Integrating Sphere Photodiode Power Sensor, InGaAs, 900 - 1650 nm, 20 W

Aperture Size  Ø12 mm

Wavelength Range 900 - 1650 nm

Power Range 10 µW - 20 W

Detector Type InGaAs Photodiode

Linearity ±0.5%

Resolution^b 10 nW

Measurement Uncertainty^c ±5%

Integrating Sphere Material (Size) Zenith^® PTFE (Ø2")

Head Temperature Measurement NTC Thermistor 4.7 kΩ

Housing Dimensions 70 mm x 74 mm x 70 mm

Active Detector Area Ø1 mm

Cable Length 1.5 m

Mounting Thread Separate 8-32 and M4 Taps, Posts Not Included

Aperture Thread Included Adapter with SM1 (1.035"-40) External Thread

 Product Drawing
