Ubiquiti Dream Machine Special Edition (UDM-SE)

Overview

The Ubiquiti Dream Machine Special Edition (UDM-SE) is an enterprise-grade, all-in-one UniFi Gateway Console designed to manage and secure your network. It serves as the central hub for the entire UniFi application suite, providing a unified management interface for your devices.

Engineered for high-performance networking, the UDM-SE offers over 3.5 Gbps of routing capability with IDS/IPS, ensuring robust security without sacrificing throughput. It is equipped with an integrated 8-port PoE/PoE+ switch and support for over 100 UniFi devices and 1,000+ client connections, making it an ideal choice for data centers and growing enterprise environments.

Designed for professional rack installations, this 1RU device features an internal 128 GB SSD for NVR recordings and a 3.5" HDD bay for expanded storage. The integrated 1.3" touchscreen provides real-time system status and management capabilities, while UniFi Power Backup readiness ensures sustained operational uptime.

Key Features

• High-Speed Routing
  Features 3.5+ Gbps routing performance with IDS/IPS for secure, high-bandwidth data handling.
• Integrated PoE Switching
  Includes an 8-port GbE RJ45 LAN switch with two PoE+ and six PoE ports for powering access points and cameras.
• Cloud Gateway Functionality
  Acts as a central console for the full UniFi application suite, streamlining device management.
• Internal NVR Storage
  Comes with a built-in 128 GB SSD specifically for NVR detection recordings.
• Storage Expandability
  Includes an integrated 3.5" HDD bay, allowing for significant storage capacity for surveillance footage.
• Advanced WAN Connectivity
  Equipped with a 10G SFP+ port and a 2.5 GbE RJ45 WAN port for flexible high-speed internet connections.
• Rack-Mount Form Factor
  Designed as a 1RU rack-mount unit for efficient integration into existing server racks.
• Intuitive Touchscreen
  Features a 1.3" built-in touchscreen for immediate visual status monitoring.

Applications

• Enterprise Network Management
• Surveillance and Security Systems
• Data Center Gateway Solutions
• Managed PoE Network Expansion

Technical Specifications

Frequently Asked Questions

Does the UDM-SE support UniFi Power Backup?
Yes, the device is designed to be UniFi Power Backup ready.

What is the maximum throughput with IDS/IPS enabled?
The UDM-SE supports routing speeds of 3.5+ Gbps with IDS/IPS enabled.

How many devices can it manage?
It is capable of supporting over 100 UniFi devices and 1,000+ client connections.

Is an HDD included for the NVR bay?
No, it includes a 128 GB SSD for NVR recordings, but the 3.5" HDD bay is provided for users to install their own storage.

What type of ports are used for WAN?
The WAN connectivity includes one 10G SFP+ port and one 2.5 GbE RJ45 port.
