Overview
The 12 Fiber MPO Breakout Cassette is a modular, factory-tested component designed to provide a secure and organized transition point between high-density MPO backbone cabling and individual duplex connectors. By converting a 12-fiber MPO interface into six duplex SC/UPC ports, this cassette enables rapid deployment and efficient cable management within data centers and enterprise networks.
Built with a standardized LGX mounting footprint, the cassette is compatible with a wide range of rack and wall mount patch panels. This modular design supports simplified installation and allows for easier access during routine network maintenance or system upgrades.
Key Features
-
Modular Design
Features an LGX compatible footprint for integration into standard patch panel enclosures. -
High-Density Transition
Converts a single 12-fiber MPO interface into six duplex SC connections for efficient routing. -
Factory Tested
Pre-terminated and factory tested to provide consistent optical performance upon installation. -
OM3 Multimode Fiber
Optimized for 50um OM3 multimode fiber applications, supporting high-speed data transmission. -
Simplified Deployment
Reduces installation time in the field by utilizing pre-terminated connectivity. -
Type A Connectivity
Standardized Type A configuration for predictable link performance and ease of pairing.
Applications
- Data Center Infrastructure
- High-Density Enterprise Networks
- Network Upgrades and Expansions
- Backbone Cabling Management
Technical Specifications
| Specification | Value |
|---|---|
| Fiber Count | 12 |
| Fiber Type | Multimode 50um OM3 |
| MPO Connector | MTP/PC Male |
| Output Connector | SC/UPC |
| Port Configuration | 6 Duplex Adapters |
| Connectivity Method | Type A |
| Form Factor | LGX Compatible |
| Housing Color | Black |
Frequently Asked Questions
What is the connectivity method of this cassette?
This cassette is built using a Type A connectivity method.
Is this cassette compatible with existing patch panels?
Yes, it features an LGX mounting footprint, making it compatible with most standard rack and wall mount patch panels.
Does this cassette use MPO or MTP connectors?
The cassette utilizes an MTP/PC male adapter on the back.
How many fibers are supported?
This unit supports 12 fibers.
What type of fiber is this cassette designed for?
It is designed for 50um OM3 multimode fiber.
