12 Fiber MPO Breakout Cassette, SM 9um OS2, MTP/APC Male LC/UPC, Type A

Overview

The 12 Fiber MPO Breakout Cassette is a high-density modular component designed to simplify fiber network deployments in data centers and telecommunications environments. This unit serves as a transition interface, converting 12-fiber MTP/MPO backbone trunk cables into standard LC duplex connectivity.

Constructed for compatibility with standard rack-mount enclosure systems, this cassette facilitates rapid installation and efficient cable management. The use of Singlemode 9/125um OS2 fiber ensures low signal attenuation and high performance for long-haul and high-speed data transmission requirements, following Polarity Type A standards for consistent network architecture.

Key Features

• High-Density Design
  Features 12 fibers within a single cassette module to maximize rack space and port density.
• Singlemode OS2 Fiber
  Optimized for 9/125um core/cladding diameter for efficient signal transmission over long distances.
• MTP/APC Male Interface
  Utilizes an MTP/APC male connector to ensure precise alignment and low reflectance.
• LC/UPC Output
  Provides 6 LC duplex ports for simple, industry-standard connectivity to active equipment.
• Polarity Type A
  Maintains consistent fiber mapping throughout the network link.
• Modular Architecture
  Enables fast, tool-less integration into standard rack-mount fiber enclosures.

Applications

• Data Center Infrastructure
• Telecommunications Networks
• Enterprise Local Area Networks
• High-Speed Fiber Backbones
• Central Office Distribution

Technical Specifications

Frequently Asked Questions

What is the primary function of this cassette?
This cassette acts as a transition point to break out a 12-fiber MPO trunk cable into 6 individual LC duplex connections for patch panel or switch connectivity.

Is this compatible with multimode fiber?
No, this model is specifically engineered for 9/125um Singlemode OS2 fiber applications.

What does the Type A polarity indicate?
Type A polarity is a standard configuration that maintains the fiber sequence, ensuring that the transmit/receive orientation remains consistent throughout the network link.

Are the MTP connectors male or female?
This specific model utilizes an MTP/APC male connector.

Can this be used in any fiber enclosure?
It is designed for standard modular fiber rack-mount enclosures that accept standard-sized MPO cassettes.
