12 Fiber MPO Breakout Cassette, SM 9um OS2, MTP/APC Male SC/APC, Type A
Roll over image to zoom in Click on image to zoom
12 Fiber MPO Breakout Cassette, SM 9um OS2, MTP/APC Male SC/APC, Type A

12 Fiber MPO Breakout Cassette, SM 9um OS2, MTP/APC Male SC/APC, Type A

Fosco ConnectSKU: F1MTPMSCAOS112
Price:
$ 393.33
Silicon Valley Based
Expert Support Since 2001
Fast CA or NY Shipping

Overview

The 12 Fiber MPO Breakout Cassette is a high-density modular component designed to transition MTP/MPO connectivity to individual SC connectors. This system facilitates rapid deployment of fiber optic links in high-density data center environments, telecommunications rooms, and enterprise networks.

Constructed for compatibility with standard rack-mount enclosures, the cassette utilizes OS2 singlemode fiber technology. By converting multi-fiber trunk cables into manageable single-fiber connections, it streamlines installation and optimizes space efficiency within fiber distribution frames.

Key Features

  • High-Density Design
    Supports 12 fibers within a single cassette module, maximizing rack space usage.
  • Singlemode OS2 Fiber
    Optimized for long-distance data transmission and high-bandwidth applications.
  • MTP/APC Connectivity
    Features industry-standard MTP interface for low-loss trunk connections.
  • SC/APC Interfaces
    Provides precise, low-reflectance connections for standard network equipment integration.
  • Polarity Type A
    Configured for standard network polarity alignment, ensuring simple installation.
  • Modular Architecture
    Allows for rapid configuration changes and upgrades without disrupting existing cabling.

Applications

  • Data Center Infrastructure
  • Telecommunications Networks
  • Enterprise Local Area Networks
  • High-Density Fiber Distribution

Technical Specifications

Specification Value
Fiber Count 12
Fiber Type Singlemode OS2 9/125um
Connector A MTP/APC Male
Connector B SC/APC
Polarity Type A

Frequently Asked Questions

What is the polarity of this cassette?
This unit is configured for Type A polarity.

Does this cassette support multimode fiber?
No, this model is designed specifically for SM 9/125um OS2 singlemode applications.

Can this be used in standard rack-mount enclosures?
Yes, it is designed for compatibility with standard fiber enclosure systems.

Are the connectors pre-polished?
Yes, the cassette arrives factory-terminated and polished for immediate use.

What does MTP/APC Male indicate?
It indicates an MTP connector with an angled physical contact (APC) polish and an alignment pin.
