Overview
The 12 Fiber Snap Pack provides a pre-terminated solution designed to simplify the splicing process for technicians working with fiber distribution frames. By utilizing a pre-loaded LGX-style adapter plate, this assembly reduces installation time in data centers and telecommunications environments.
The unit features 12 fibers of 50um OM2 multimode glass protected by a flexible spiral wrap for enhanced cable management. Each pigtail is constructed with 900um tight-buffered fiber, ensuring performance and durability during routine splicing operations.
Key Features
-
Pre-Terminated Design
Comes pre-loaded with connectors to significantly reduce on-site termination time. -
LGX Compatibility
Standard adapter plate footprint ensures seamless integration into existing fiber distribution frames. -
Flexible Spiral Wrap
Protects pigtails while allowing for easy organization and removal during cable management. -
900um Tight Buffer
Utilizes industry-standard tight-buffered fiber to provide physical protection for the strands. -
Low Insertion Loss
Engineered with a maximum insertion loss of 0.4dB to maintain signal integrity. -
Color-Coded Fiber
Includes standard industry color-coding for efficient identification during the fusion splicing process.
Applications
- Fiber distribution frames
- Data center cross-connects
- Telecommunication central offices
- Premise fiber distribution
Technical Specifications
| Specification | Value |
|---|---|
| Fiber Count | 12 |
| Fiber Type | Multimode 50um OM2 |
| Connector Type | SC/PC |
| Cable Length | 3 Meters |
| Plate Color | Black |
| Insertion Loss | 0.4dB (Max) |
Frequently Asked Questions
What is an LGX plate?
LGX refers to a standard industry footprint for fiber optic adapter plates, allowing them to be swapped into most standard rack-mount enclosures.
Are these pigtails color-coded?
Yes, the fibers follow standard industry color coding (Blue, Orange, Green, Brown, Slate, and White) for easy identification.
Can I order a custom length?
Yes, custom configurations including varying pigtail lengths and connector types are available upon request.
What type of fiber is used?
The assembly is constructed using Corning 900um tight-buffered fiber.
Is the plate material included?
Yes, this is a complete assembly including the black adapter plate, adapters, and pre-terminated pigtails.
