Overview
This 12-fiber multimode fiber optic cable is engineered for both indoor and outdoor deployments, providing versatility for various networking environments. Featuring 50um OM4 fiber, it is optimized for high-speed data transmission and is suitable for enterprise backbones, data centers, and campus-wide networking applications.
The cable is constructed with a 5.8mm outer diameter and includes Aluminum Interlocking Armor (AIA). This metallic layer offers robust mechanical protection against crushing forces and rodent interference, while the plenum-rated jacket allows for installation in air-handling spaces without the need for additional conduit. This design ensures both physical durability and compliance with strict indoor fire safety standards.
Key Features
-
Aluminum Interlocking Armor (AIA)
Provides high crush resistance and protection against environmental hazards for long-term cable integrity. -
Plenum Rated Jacket
Ensures compliance with indoor fire safety codes for installation in ducts and plenums. -
Indoor/Outdoor Versatility
Allows for seamless transitions between building environments and external plant locations. -
12-Fiber Count
Supports multiple high-bandwidth data channels in a single, compact cable assembly. -
OM4 Multimode Fiber
Optimized for 10Gbps, 40Gbps, and 100Gbps network speeds over extended reach. -
5.8mm Outer Diameter
Maintains a slim profile for easier routing in congested cable trays and conduits.
Applications
- Enterprise LAN backbones
- Data center high-density interconnects
- Campus building-to-building links
- Air-handling space (plenum) installations
- Harsh indoor environments requiring rodent protection
Technical Specifications
| Specification | Value |
|---|---|
| Fiber Count | 12 |
| Fiber Mode | Multimode (OM4) |
| Core Diameter | 50um |
| Outer Diameter | 5.8mm |
| Armor Type | Aluminum Interlocking Armor (AIA) |
| Jacket Rating | Plenum |
Frequently Asked Questions
Is this cable suitable for direct burial?
No, while it is rated for indoor/outdoor use, this cable is not designed for direct burial applications.
Can I use this cable in a ceiling plenum?
Yes, the jacket is plenum-rated, making it safe for use in air-handling spaces.
What is the primary benefit of the armor?
The Aluminum Interlocking Armor provides superior crush resistance and protects the glass fibers from physical damage and rodents.
Is this OM4 fiber compatible with OM3 equipment?
Yes, OM4 is backward compatible with OM3 systems.
Is this cable sold in fixed lengths?
This cable is sold by the meter to accommodate specific project requirements.
