Overview
The 12-fiber MPO cassette is designed to provide a secure and efficient transition between MPO backbone cabling and standard SC-interface distribution cables. By utilizing an integrated MPO connector, it facilitates rapid deployment and modular connectivity within high-density data center environments and enterprise network infrastructures.
Engineered for multimode OM3 fiber applications, this cassette features a Type B polarity configuration. It is housed in a compact, durable enclosure suitable for standard rack-mount installations, ensuring organized cable management and reduced installation time during network upgrades or initial setups.
Key Features
-
High-Density 12-Fiber Capacity
Supports up to 12 fiber connections in a single modular unit, maximizing rack space utilization. -
OM3 Multimode Compatibility
Optimized for 50/125 micron OM3 fiber to support high-bandwidth network requirements. -
Factory-Terminated MTP Interface
Reduces field installation time and ensures consistent optical performance with precise factory alignment. -
Type B Polarity Configuration
Standardized wiring scheme designed to facilitate simplified connectivity in parallel optic systems. -
SC/UPC Interface
Utilizes widely recognized SC/UPC connectors for seamless integration with existing network patch panels. -
Modular Design
Allows for easy installation and removal from compatible rack-mount chassis systems.
Applications
- Data Center Backbone Cabling
- Enterprise LAN/WAN Networks
- High-Density Patch Panels
- Telecommunications Distribution Hubs
Technical Specifications
| Specification | Value |
|---|---|
| Fiber Count | 12 |
| Fiber Type | Multimode OM3 |
| Connector A | MTP Male |
| Connector B | SC/UPC |
| Polarity | Type B |
Frequently Asked Questions
What is the primary benefit of using a cassette system?
Cassette systems enable plug-and-play connectivity, significantly reducing the need for field splicing and accelerating deployment times in high-density environments.
Is this cassette compatible with OM4 fiber?
While this unit is designed for OM3, OM4 is backward compatible; however, ensure your entire link budget accounts for the specific fiber grade used.
What does "Type B" polarity mean?
Type B polarity is a specific mapping standard for MPO connectivity where the fibers are crossed to ensure proper transmit-to-receive alignment.
Can this be mounted in standard rack enclosures?
Yes, this cassette is designed to fit into standard rack-mount enclosure systems meant for modular fiber cassettes.
Does this cassette include the adapter plates?
The cassette housing acts as the interface, providing the SC/UPC ports on the front and the MTP port on the rear.
