Overview
The 1x4 Optical Splitter in an OSP (Outside Plant) cassette is designed for hardened environmental applications, providing robust fiber protection for external network deployments. This unit is specifically engineered for efficient use within cabinets and enclosures where space optimization is critical.
Featuring integrated jacketed leads, this splitter allows for rapid field installation. The OSP packaging ensures durability against environmental stressors while maintaining optical integrity for high-performance signal distribution in FTTx and other outside plant infrastructures.
Key Features
-
OSP Hardened Design
Protected enclosure specifically built for outdoor plant environments, ensuring long-term durability. -
Space-Efficient Form Factor
Compact 100mm x 80mm x 10mm dimensions maximize capacity in field cabinets and splice enclosures. -
High Optical Compatibility
Wide operating wavelength range of 1260nm to 1650nm supports various network standards. -
Quick Installation
Jacketed leads simplify routing and termination, reducing time-on-site for technicians. -
Industry Standard Connectors
Equipped with SC/APC connectors to ensure low-reflectance and high-quality optical connections. -
1x4 Split Configuration
Standardized split ratio for reliable signal distribution in passive optical networks.
Applications
- FTTx Deployments
- Passive Optical Networks (PON)
- Outdoor Cabinet Infrastructure
- Fiber Distribution Hubs
- Outside Plant Splice Closures
Technical Specifications
| Specification | Value |
|---|---|
| Split Ratio | 1x4 |
| Connector Type | SC/APC |
| Operating Wavelength | 1260nm - 1650nm |
| Package Dimensions | 100mm L x 80mm W x 10mm H |
| Lead Jacket Diameter | 2mm |
Frequently Asked Questions
What does OSP package mean?
OSP stands for Outside Plant. It refers to equipment designed to withstand the environmental challenges found in outdoor environments, such as moisture and temperature variations.
Can this splitter be used for other split ratios?
This specific model is a 1x4 configuration. Other ratios including 1x8, 1x16, 1x32, 1x64, 2x16, and 2x32 are also available in this product series.
What is the wavelength range?
The operating wavelength for this splitter is 1260nm to 1650nm.
Does this include connectors?
Yes, this unit comes pre-terminated with SC/APC connectors.
What are the dimensions of the cassette?
The OSP package measures 100mm in length, 80mm in width, and 10mm in height.
