Overview
This 24-fiber multimode 50µm OM3 distribution cable is designed for reliable high-speed data transmission in indoor environments. Featuring a ruggedized construction with Aluminum Interlocking Armor (AIA), this cable provides superior mechanical protection against crush, impact, and rodent damage, making it suitable for high-traffic or industrial routing where standard cabling might be vulnerable.
The plenum-rated jacket ensures compliance with building codes for fire safety in air-handling spaces. With an outside diameter of 17.45mm and a high-density fiber count, this cable is an ideal backbone solution for data centers, campus environments, and enterprise networking infrastructures requiring durable, long-term fiber connectivity.
Key Features
-
Aluminum Interlocking Armor
Provides exceptional mechanical protection and crush resistance without the need for additional innerduct. -
24-Fiber Capacity
Supports high-density connectivity for demanding network backbones and enterprise applications. -
Plenum Rated Jacket
Meets stringent fire safety standards for installation in air-handling plenums and building ductwork. -
50µm OM3 Multimode Fiber
Optimized for 10 Gigabit Ethernet performance over extended reach in indoor network architectures. -
Distribution Design
Allows for easy field termination and routing within enclosures or cable trays. -
17.45mm Outside Diameter
Compact profile relative to its robust protective armor, aiding in space-constrained cable management.
Applications
- Data center backbones
- Enterprise LAN cabling
- Indoor horizontal and vertical routing
- Industrial automation environments
- High-density fiber optic distribution
Technical Specifications
| Specification | Value |
|---|---|
| Fiber Count | 24 |
| Fiber Type | Multimode 50µm (OM3) |
| Jacket Rating | Plenum |
| Armor Type | Aluminum Interlocking Armor (AIA) |
| Outside Diameter | 17.45mm |
| Cable Construction | Distribution |
Frequently Asked Questions
Is this cable suitable for outdoor use?
This cable is primarily designed for indoor applications and features a plenum-rated jacket; it is not rated for direct-burial or long-term outdoor environmental exposure.
Does the aluminum armor require grounding?
While armor provides protection, standard industry practice for interlocking armor usually involves bonding to a common ground point if the armor is used as part of a metallic path, depending on local electrical codes.
What is the maximum distance for OM3 fiber at 10Gbps?
OM3 fiber is typically rated for 10Gbps speeds up to 300 meters.
Can this cable be installed in cable trays?
Yes, the interlocking armor provides the necessary mechanical protection for installation in open cable trays.
Is this sold as a pre-terminated assembly?
No, this item is sold as raw bulk cable per meter.
