3M EMSD Diamond Lapping Film Type H is a high-performance polishing abrasive designed specifically for demanding fiber optic connector processing. This film utilizes micro-graded diamond minerals bonded to a precision-engineered 3 mil polyester backing, ensuring consistent material removal rates and superior surface finishes on fiber end-faces.
Engineered with a tougher resin system and higher diamond concentration compared to standard films, Type H is optimized for cutting and polishing hard materials, including ceramic, stainless steel, plastic, and composite ferrules. Its uniform construction provides predictable, repeatable results, making it an essential component for achieving high-yield connector manufacturing and maintenance.
Key Features
-
High Diamond Content
Formulated with a higher density of diamond abrasive for efficient material removal on hard ceramic ferrules. -
Uniform Polyester Backing
Features a 3 mil thickness that ensures flatness and consistency across the entire polishing process. -
Type H Resin System
Utilizes a tougher resin binder designed to resist degradation during aggressive polishing cycles. -
Plain Back Design
Non-adhesive backing allows for easy mounting and removal from polishing platens without residue. -
Precise Grading
Micro-graded diamond particles provide predictable, repeatable finish quality for every connector. -
Versatile Application
Suitable for use on a wide variety of ferrule materials, including stainless steel, composite, and glass.
Applications
- Fiber optic connector polishing
- Ceramic ferrule finishing
- Stainless steel ferrule processing
- Composite and plastic ferrule polishing
- Precision fiber end-face preparation
Package Contents
- 50 x 3M Type H Diamond Lapping Film Discs (4" diameter)
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | 3M |
| Part Number | HDF4XN03662XW50 |
| Film Type | Type H (Diamond) |
| Grit Size | 3um |
| Format | 4-inch Disc |
| Backing Material | Polyester |
| Backing Thickness | 3 mil |
| Adhesive | None (Plain Back) |
| Quantity per Pack | 50 |
Frequently Asked Questions
Is this film self-adhesive?
No, this is a plain-back film without pressure-sensitive adhesive (PSA).
What ferrule materials is this film compatible with?
It is optimized for ceramic, stainless steel, plastic, and composite ferrules.
What is the backing thickness of the film?
The polyester backing is 3 mil thick.
How many discs are included in one order?
Each package contains 50 individual 4-inch discs.
Why is Type H film preferred for ceramic ferrules?
Type H features a tougher resin and higher diamond content, specifically engineered to cut hard ceramic materials efficiently.
