SC QuickPort Fiber Adapter, Multimode, MFR Leviton

Leviton Part No.: 41085-MXC

  • $ 11.92 or



SC QuickPort Fiber Adapter, Multimode, MFR Leviton

QuickPort Fiber Optic Adapters provide connectivity for workstation cabling termination on single mode and multimode fiber cable.

QuickPort bulkhead modules snap into any housing with the QuickPort name: flush and surface mount outlets; Multimedia Outlet System (with adapter); patch panels, and patch blocks.

Download Product Spec Sheet:

Design Considerations:

  • Quickport adapters snap into QuickPort panels or modules.
  • ST, FC, and SC QuickPort Adapters are available in standard colors of ivory, white, grey, black, and almond
  • SC QuickPort Adapters are also available in blue for identification in single-mode applications
  • LC QuickPort adapters are available in standard colors as well as blue, yellow, red, green, and orange as part of the Secure Keyed LC system
  • Use in permanent or temporary applications
  • ST, FC, SC, and LC QuickPort Adapters are available in zirconia ceramic or phosphor bronze sleeves, and are compatible with single-mode or laser optimized multimode applications

Standards Compliance:

  • UL Listed; NOM and ACA certified; compliant with TIA-568-C.3 TIA 604.

Dimensions:

  • ST Fiber Adapter: .644" h x .575" w x 1.3" d
  • FC Fiber Adapter: .644" h x .575" w x 1.01" d
  • SC Fiber Adapter: .644" h x .575" w x 1.354" d
  • LC Fiber Adapter: .644" h x .575" w x 1.414" d
  • MT-RJ Fiber Adapter: .644" h x .575" w x 1.102" d

Materials:

  • Snap in module bodies are high-impact, fire retardant plastic rated UL 94V-0
  • ST Fiber Adapter: Single-mode zirconia sleeve, LOMM zirconia sleeve, Multimode phosphor bronze sleeve
  • FC Fiber Adapter: Single-mode zirconia sleeve, LOMM zirconia sleeve, Multimode phosphor bronze sleeve
  • SC Fiber Adapter: Single-mode zirconia sleeve, LOMM zirconia sleeve, Multimode phosphor bronze sleeve
  • LC Fiber Adapter: Single-mode zirconia sleeve, LOMM zirconia sleeve, Multimode phosphor bronze sleeve
  • MT-RJ Fiber: MT-RJ coupling
  • MTP: MTP coupling

Specification:

  • QuickPort Fiber Optic Adapters for fiber optic cabling media shall be individual snap-in style and shall fit into QuickPort housings.
  • The ST, FC, SC, and LC Adapters shall be compatible with single-mode, multimode, and laser optimized multimode connectors, and available in ziroconia ceramic or phosphor bronze sleeves.
  • ST, FC, MT-RJ, MTP, and SC QuickPort Adapters shall be available in standard colors of ivory, white, grey, black and almond.
  • SC QuickPort Adapters shall also be available in blue for identification in single-mode applications.
  • LC QuickPort adapters shall be available in standard colors as well as blue, yellow, red, green, and orange as part of the Secure Keyed LC system.
