Leviton's QuickPort Recessed-Angled Patch Panel features a customizeable design for fiber and copper applications, accepting all QuickPort Snap-in Modules for optimum rack density on industry standard racks. The panel features a dual-angle design to easily route cables into vertical cable managers, reducing the need for horizontal, front cable management bars.

Features:

• Improved accessibility brings termination field closer toinstaller for easier termination
• Low profile provides more aisle space in closets
• Unique dual-angle design reduces cable bend radiusand keeps terminations within a standard 3" depth rack

Design Considerations:

• Mounts on industry standard 19" wide equipment racks
• Accepts all QuickPort Snap-in Modules for copper andfiber applications
• Write-on blocks and port numbers are silk-screened in white

Physical Specifications:

Dimensions:

• 24-port: 1.72"H x 19"W x 4.08"D
• 48-port: 3.50"H x 19"W x 4.08"D
• 72-port: 3.50"H x 19"W x 4.08"D

Capacity: 24-port, 48-port, 72-port

Materials: 16-gauge steel

Mounting: 19" rack-mount

Color: Painted black with white silk-screening
