Overview
This 6-fiber pigtail assembly is designed for high-density fiber optic splicing applications. Each assembly features 900um tight-buffered optical fiber, ensuring robustness during the termination and routing process. These pigtails are engineered for compatibility with standard fusion splicing environments, providing a reliable transition between OSP cabling and patch panels.
Constructed with high-quality multimode 50um OM2 fiber, the assembly includes factory-terminated ST/PC connectors with black boots. The fibers are color-coded to industry standards—Blue, Orange, Green, Brown, Slate, and White—to facilitate efficient and accurate fiber management during installation.
Key Features
-
Color-Coded Fibers
Standardized color-coding (Blue, Orange, Green, Brown, Slate, White) ensures easy identification and faster, error-free splicing. -
Corning Fiber Construction
Manufactured using high-quality Corning tight-buffered fiber for consistent transmission performance. -
Optimized Insertion Loss
Features a maximum insertion loss of 0.4dB, supporting efficient signal integrity in your network. -
Standard 3-Meter Length
Pre-cut to a 3-meter length, providing sufficient slack for most standard rack-mount and wall-mount enclosure configurations. -
Factory Terminated
Factory-terminated ST/PC connectors ensure consistent performance compared to field-terminated solutions. -
Robust 900um Buffer
900um buffer coating provides enhanced protection for the fiber during handling and routing in tight spaces.
Applications
- High fiber count fusion splicing
- Rack and wall mount enclosure termination
- Fiber distribution frames
- Data center and enterprise networks
Technical Specifications
| Specification | Value |
|---|---|
| Fiber Count | 6 |
| Fiber Type | Multimode 50um OM2 |
| Connector Type | ST/PC |
| Fiber Diameter | 900um |
| Insertion Loss | 0.4dB (Max) |
| Cable Length | 3 Meters |
| Boot Color | Black |
Frequently Asked Questions
Are these pigtails compatible with fusion splicers?
Yes, these 900um tight-buffered pigtails are specifically designed for high fiber count fusion splicing applications.
What are the fiber colors for this 6-pack?
The fibers are color-coded to industry standards: Blue, Orange, Green, Brown, Slate, and White.
What is the maximum insertion loss?
The pigtails have a typical maximum insertion loss of 0.4dB.
Is the fiber used industry-standard?
Yes, these pigtails are manufactured using Corning tight-buffered optical fiber.
Can I order custom lengths?
For custom fan-out lengths or specific configurations, please contact our support team.
