Overview
The 4X SHD MTP 12 Pack Adapter Plate is a modular, high-density solution engineered for modern network infrastructures. Designed for seamless integration, this plate provides a reliable pass-through interface for connecting multiple trunk cables utilizing MPO connectors.
Engineered for dense environments, this adapter plate facilitates efficient cable organization and reduces installation time. It is specifically compatible with the 1RU 4X Slim High Density (SHD) Cassette Enclosure, making it an ideal component for data center patch panels and enterprise fiber management applications.
Key Features
-
High-Density Configuration
Features 12 MPO mating sleeves in a compact footprint to maximize rack space. -
Polarity Type A
Designed for Key Up-Key Down MPO configuration to maintain structured network polarity. -
Modular Compatibility
Engineered to install directly into the 1RU 4X SHD Enclosure, ensuring a secure fit. -
Versatile Fiber Support
Compatible with both singlemode and multimode fiber installations. -
Durable Construction
Finished in a professional black color to blend with standard rack equipment. -
Efficient Installation
Simplifies trunk cable management to reduce labor costs in high-density deployments.
Applications
- Data Center Infrastructure
- Enterprise Network Patching
- Central Office Fiber Management
- High-Density Cable Distribution
Technical Specifications
| Specification | Value |
|---|---|
| Part Number | F1SHDMPO12A |
| Adapter Count | 12 MPO Mating Sleeves |
| Polarity | Type A (Key Up-Key Down) |
| Fiber Type | Singlemode / Multimode |
| Compatibility | 1RU 4X SHD Enclosure (p/n F1RM1RU4XHD) |
| Color | Black |
Frequently Asked Questions
Is this plate compatible with standard LGX enclosures?
No, this adapter plate is specifically designed for the 4X SHD Slim High Density series enclosure.
What does the Type A polarity indicate?
Type A indicates a Key Up-Key Down MPO alignment, which is a standard configuration for maintaining proper fiber channel order.
Does this include the MPO couplers?
Yes, it comes equipped with 12 MPO mating sleeves ready for installation.
Can I use this with singlemode or multimode fiber?
Yes, the adapter plate is designed to accommodate both fiber types.
Are there other colors available?
Yes, this series is also available in off-white; please contact sales for availability.
