AFL 8500-05-0001MZ One-Click Cleaner SC, ST, FC 2.5mm Ferrule

Overview

The AFL 8500-05-0001MZ One-Click® Cleaner is designed for efficient, consistent cleaning of SC, ST, and FC fiber optic connectors. It is optimized for use with 2.5mm ferrules in adapters or on exposed connector end-faces, making it a critical tool for maintaining signal integrity in fiber optic networks.

This cleaning tool features a precise mechanical action that automatically advances cleaning tape, ensuring a fresh, clean surface for every engagement. Its compact, ergonomic form factor allows for effective use in high-density patch panels and confined enclosures where traditional cleaning tools may not fit. It supports both dry and wet cleaning methods, providing versatility for various contamination levels.

Key Features

• Single-Action Operation
  Features a push-type mechanism that cleans in one engagement, saving time during field maintenance.
• Versatile Cleaning
  Compatible with both dry and wet cleaning techniques for effective removal of oils and dust.
• Extended Tip Reach
  Adjustable tip extends from 1.77" to 3.15" to reach deeply recessed connectors.
• High Capacity
  Provides over 500 cleanings per unit, offering a low cost-per-clean.
• Compact Design
  Ergonomic body fits easily into tight spaces such as crowded data center patch panels.
• Consistent Results
  Automatically advances fresh tape to prevent cross-contamination between ports.

Applications

• SC, ST, and FC connector cleaning
• Data center patch panel maintenance
• Field fiber installation
• Laboratory fiber testing

Technical Specifications

Frequently Asked Questions

Is this cleaner reusable?
The unit is designed for 500 cleanings and is not intended to be refilled or reused once the tape is exhausted.

Can I use this for LC connectors?
No, this model is specifically for 2.5mm ferrules (SC, ST, FC). For LC/MU connectors, a 1.25mm cleaner is required.

Does it require cleaning solvent?
It can be used as a dry cleaner, but it is compatible with cleaning fluids if needed for stubborn contaminants.

How do I know when it is empty?
The internal tape mechanism will stop advancing, indicating the 500-cleaning cycle is complete.

Is it suitable for field use?
Yes, the durable, compact design is specifically engineered for the demands of field technicians and installation environments.
