AFL CLETOP 8500-10-0033MZ MPO/MTP Connector Cleaner, White

Overview

The AFL CLETOP 8500-10-0033MZ MPO/MTP Ferrule Cleaning Cassette is a professional-grade tool designed for the efficient cleaning of MPO and MTP connectors, specifically those featuring pins. Utilizing a high-performance white fine-weave cleaning tape, this cassette effectively removes debris and contaminants through capillary action, trapping particles within the tape's micro-pockets.

Engineered for both field and manufacturing environments, this dry-cleaning system eliminates the need for hazardous solvents, such as IPA alcohol or Freon, providing a safe and environmentally friendly solution. The compact design and simple operation ensure consistent, high-quality results for network engineers and fiber technicians tasked with maintaining high-density optical networks.

Key Features

• Dry Cleaning Method
  Uses a specially formulated 2-µm fiber weave dry cloth to lift contaminants without the need for toxic or flammable solvents.
• High Capacity
  Each replacement reel provides over 400 cleanings, offering an economical solution for high-volume maintenance.
• Anti-Static Construction
  Features anti-static properties to prevent the attraction of dust particles after cleaning.
• Dual-Slot Design
  Includes a push-down lever that exposes two slots, allowing for two cleaning swipes per connector to ensure thorough removal of oils and grease.
• Compact Portability
  Lightweight and small-form factor design for easy storage in field technician kits.
• MPO/MTP Specialized
  Optimized specifically for cleaning MPO/MTP ferrules, including those with guide pins.

Applications

• Data center high-density fiber interconnects
• Field installation and maintenance of MPO/MTP trunks
• Fiber optic manufacturing facilities
• Fiber optic testing and certification workflows

Technical Specifications

Frequently Asked Questions

Does this cleaner use alcohol?
No, the CLETOP system is a dry-cleaning method that does not require alcohol or any other toxic solvents.

Can I replace the cleaning tape?
Yes, replacement reels are available separately and can be easily installed into the cassette.

Is this safe for MPO connectors with pins?
Yes, this specific model (8500-10-0033MZ) is designed to clean MPO/MTP connectors that have pins.

How many cleanings can I get from one reel?
Each reel provides at least 400 cleaning cycles.

How does it capture dirt?
It uses capillary action to lift oil, grease, and dust from the ferrule surface and traps the debris in the micro-pockets of the woven cloth.
