Overview
The AFL FUSEConnect SC PC connector is a field-installable, fusion-spliced connector designed for high-performance multimode optical networks. By utilizing a fusion splicing process rather than traditional mechanical or epoxy-based termination methods, this connector eliminates the need for adhesives, crimping, or polishing in the field. This advanced approach reduces potential operator error and minimizes connector scrap, ensuring consistent optical performance.
These connectors are engineered to address the return loss concerns commonly found in analog optical networks. They are compatible with a wide range of fusion splicing platforms, including Fujikura fusion splicers, making them a versatile choice for network technicians and contractors working in data centers or enterprise environments requiring reliable 10G connectivity.
Key Features
-
Field Installable
Designed for rapid, high-quality termination directly in the field. -
No Adhesives or Polishing
Fusion-spliced design removes the need for messy glues or time-consuming polishing steps. -
Minimized Connector Scrap
Advanced termination process significantly reduces the potential for costly errors during installation. -
Industry Standard Compatibility
Fully intermateable with existing standard SC and LC connector hardware. -
Fusion Splicer Compatible
Works seamlessly with Fujikura and most other common fiber holder-based fusion splicing platforms. -
TIA-568.3 Compliance
Meets established ANSI/TIA-568.3 standards for fiber optic cabling performance.
Applications
- 10 Gigabit Ethernet Networks
- Data Center Connectivity
- Analog Optical Networks
- Field Repair and Maintenance
Package Contents
- 6 x SC PC Multimode 50um 10G Connectors
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | AFL |
| Connector Type | SC |
| Polish | PC |
| Fiber Type | Multimode 50um (10Gig) |
| Cable Diameter | 3.0mm |
| Quantity | 6 per pack |
| Standards | ANSI/TIA-568.3 |
Frequently Asked Questions
Are these connectors reusable?
No, FUSEConnect connectors are designed for permanent installation via fusion splicing.
Do I need specialized equipment to install these?
Yes, an compatible fusion splicer is required for termination.
Are these compatible with non-Fujikura splicers?
They are compatible with most common fiber holder-based fusion splicing platforms.
Does this kit include 6 connectors?
Yes, each package contains 6 individual connectors.
Is polishing required?
No, the fusion-spliced design eliminates the need for field polishing.
