Overview
The AFL FUSECONNECT field-installable connector provides a high-performance solution for terminating singlemode fibers in the field. By utilizing fusion splicing technology, these connectors ensure a reliable, permanent connection without the need for adhesives, crimping, or manual polishing. This process significantly reduces the risk of operator error and minimizes connector scrap during installation.
Designed for analog optical networks, the FUSECONNECT system addresses stringent return loss requirements. This next-generation connector series offers an improved design for simplified, efficient installation. Each unit is compatible with common industry fusion splicers, making it a versatile choice for network technicians and contractors working in various optical infrastructure environments.
Key Features
-
Fusion Spliced Termination
Uses fusion technology to create a robust, permanent connection with low insertion loss. -
Polishing-Free
Eliminates the time-consuming and inconsistent field-polishing process. -
Adhesive-Free Design
Requires no epoxies or adhesives, streamlining the assembly process. -
Analog Network Optimized
Engineered to meet the strict return loss requirements of analog optical networks. -
Broad Compatibility
Works with most fiber holder-based fusion splicers, including Fujikura models. -
Simplified Design
Next-generation construction allows for faster and more consistent field terminations. -
Standard Compliance
Meets ANSI/TIA-568.3 requirements for performance and interoperability. -
Packaged for Efficiency
Supplied in a 6-pack to suit standard installation site requirements.
Applications
- Analog optical networks
- Field restoration and repairs
- FTTx installations
- Enterprise network deployments
- Data center cable management
Package Contents
- 6 x FUSECONNECT SC UPC Singlemode 3.0mm Connectors
Compatibility
Fusion Splicers- Fujikura field fusion splicers
- Other industry standard fiber holder-based fusion splicers
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | AFL |
| Connector Type | SC |
| Polish | UPC |
| Fiber Type | Singlemode |
| Cable Diameter | 3.0mm |
| Pack Size | 6 |
| Installation Method | Fusion Splice |
| Standards | ANSI/TIA-568.3 |
Frequently Asked Questions
Is polishing required during installation?
No, the FUSECONNECT system uses fusion splicing technology, which eliminates the need for field polishing, adhesives, or crimping.
Are these connectors compatible with my existing fusion splicer?
These connectors are compatible with most industry-standard fiber holder-based fusion splicers, including all Fujikura field models.
Do these meet industry standards?
Yes, they are designed to meet ANSI/TIA-568.3 compliance.
What type of fiber are these designed for?
These specific connectors are designed for singlemode fiber applications.
How many connectors are included in this purchase?
Each SKU includes a pack of 6 connectors.
Downloads
