Wall Mount Interconnect Enclosure – Black
Holds (2) LGX Adapter Plates

This wall-mount interconnect enclosure provides a secure and flexible convergence point for fiber interconnection and splicing in indoor wall-mount applications. Constructed from solid steel, it is designed to protect sensitive components while offering efficient cable and fiber management for both ingress and egress points.

The enclosure supports up to two LGX-compatible adapter plates or optical modules and delivers a patch-and-splice density of 12 to 24 fibers. Dual access doors separate provider and customer access and are independently lockable using a common padlock or tube-style keyed lock. Integrated roll-formed hinges eliminate potential fiber pinch points during installation or servicing. Optional splice tray and holder kits are available for splice management, and the enclosure is compatible with AFL PoliMOD® products and XFM optical cassettes.

Download product spec sheet (PDF)

Specifications

• Capacity:

  • Holds (2) LGX-compatible adapter plates or optical modules (not included)

  • Supports 12 to 24 fiber patch and splice density

• Construction:

  • Material: Solid steel

  • Finish: Black powder coat

• Design Features:

  • Dual doors with separate locking options for provider and customer access

  • Splicing and patching capability

  • Integrated cable and fiber management at ingress and egress points

  • Roll-formed hinges to prevent fiber pinch points

  • Top or bottom cable entry with dust-resistant grommets

  • Dual-hasp locking/security system

  • Compatible with PoliMOD® products and XFM optical cassettes

• Optional Accessories:

  • Splice tray and holder kits (FM002827-1 or FM002827-2), sold separately

• Dimensions:

  • 12.0" H × 14.0" W × 2.5" D

• Weight:

  • 10.65 lbs (empty)

• Notes:

  • Adapter plates and optional splice trays sold separately
