Overview
This Category 6 patch cable is designed for reliable high-speed data transmission in networking environments. Featuring a 25ft length, it is suitable for connecting switches, routers, and patch panels within data centers and office networks.
The cable is constructed with 4-pair stranded, 24 AWG unshielded conductors. It is pre-terminated with snagless RJ-45 boots, which provide mechanical protection to the connector release tab during installation in high-density areas. This cable is Non-Plenum (CMR) rated for standard indoor installation requirements.
Key Features
-
RJ-45 Connectivity
Pre-terminated with 8-position RJ-45 plugs for plug-and-play network deployment. -
Snagless Boots
Integrated boots prevent the locking tab from snagging on other cables or hardware during cable management. -
24 AWG Conductors
Stranded 24 AWG copper wiring provides the flexibility needed for patching and frequent handling. -
4-Pair Configuration
Standard 4-pair construction supports high-performance Category 6 data rates. -
CMR Jacket
Non-Plenum rated jacket material meets standard vertical-tray fire safety requirements. -
Universal Wiring
Supports T568A and T568B wiring configurations for broad compatibility with existing network infrastructure.
Applications
- Local Area Network (LAN) patching
- Data center equipment connectivity
- Workstation-to-wall-plate links
- Patch panel interconnections
Technical Specifications
| Specification | Value |
|---|---|
| Cable Type | Cat 6 |
| Connector A | RJ-45 |
| Connector B | RJ-45 |
| Length | 25ft |
| Color | Yellow |
| Conductor Gauge | 24 AWG |
| Conductor Type | Stranded |
| Rating | CMR (Non-Plenum) |
| Wiring Standard | T568A/T568B |
Frequently Asked Questions
What does the snagless boot feature do?
The snagless boot covers the RJ-45 tab to prevent it from catching or breaking when pulling the cable through cable management pathways.
Is this cable suitable for use in plenum air spaces?
No, this cable is CMR rated (Non-Plenum). It is intended for general riser applications and should not be used in environmental air-handling spaces.
Does this cable support both T568A and T568B wiring?
Yes, the cable is wired to support universal wiring configurations.
What is the conductor size?
This cable uses 24 AWG stranded copper conductors.
Is this cable shielded?
No, this is an unshielded (UTP) cable.
