ST Single Mode and Multimode Fiber Connector Keystone Module, Mfr SignaMax
Move your mouse over image or click to enlarge

ST Single Mode and Multimode Fiber Connector Keystone Module, Mfr SignaMax

SignaMax Part No.: CMK-ST

  • $ 4.23 or


ST Single Mode and Multimode Fiber Connector Keystone Module, Mfr SignaMax

Optical Fiber Modules bring ST. SC, LC and MT-RJ fiber connectors to the workstation. Fiber couplers are provided with phosphor bronze sleeves suitable for both multimode and singlemode applications.

Signamax Connectivity Systems offers a wide range of keystone connector modules designed to create a customized multimedia solution in any single or double gang faceplate or surface mount box.

Optical Fiber Modules bring ST. SC, LC and MT-RJ fiber connectors to the workstation. Fiber couplers are provided with phosphor bronze sleeves suitable for both multimode and singlemode applications

Product Features:

  • Guaranteed to meet or exceed TIA-568-C.3 performance requirements
  • Multi-purpose keystone design equally suitable as a work area outlet and a patch panel port
  • Available in OM1, OM2, OM3, and singlemode versions
  • Adapters are equipped with phosphor bronze sleeves supporting both multimode and singlemode connections

Download Product Spec Sheet:

Specifications:

TRANSMISSION PERFORMANCE: ANSI/TIA-568-C.3: meets or exceeds performance specifications

TRANSMISSION MEDIA: Multimode (OM1, OM2, OM3) and singlemode (OS1) optical fiber with 125-‰_m cladding diameter

CONNECTOR TYPE: FOCIS-compliant ST, SC, MT-RJ, and LC

Insertion loss: 0.2 dB typical, 0.4 dB maximum, Insertion loss increase after 500 mating cycles: 0.1 dB

CONSTRUCTION: Housing: high impact thermoplastic, UL94V-0 fire retardant, Alignment sleeve: phosphor bronze

MECHANICAL: Alignment sleeve retention force: 200-600 gf, Mating cycle life: min 500 cycles

FOOTPRINT: Standard keystone footprint

MOUNTING DIMENSIONS:

SC: D 28 mm H 19.3 mm W 16.9 mm, D 1.1 in H 0.76 in W 0.67 in

LC: D 25 mm H 19.3 mm W 16.9 mm, D 1.0 in H 0.76 in W 0.67 in

MT-RJ: D 28 mm H 19.3 mm W 16.9 mm, D 1.1 in H 0.76 in W 0.67 in

ST: D 30 mm H 19.3 mm W 16.9 mm, D 1.2 in H 0.76 in W 0.67 in

ENVIRONMENTAL CONDITIONS: Storage: -40 †­C-+85 †­C (-40 †­F-+185 †­F), Operation: -40 †­C-+85 †­C (-40 †­F-+185 †­F), RH (operation): max non-condensing 93 %

COMPLIANCE: ANSI/TIA-568-C.3, FOCIS, UL 94V-0

APPLICATIONS: FOIRL, 10BASE-FL, 10BASE-FB, 10BASE-SX, Token Ring 4/16, 100VG-Any LAN, 100BASE-FX, 100BASE-SX, FDDI, ATM 52/155/622, Fibre Channel 266/1062, 1000BASE-SX, 1000BASE-LX, 10GBASE-S, 10GBASE-L, 10GBASE-E, 10GBASE-LX4

WARRANTY: 5-year limited component warranty, 10-year Signamax Link/Channel Warranty, 15-year Signamax Extended Component Warranty, 25-year Signamax Cabling System Warranty
