Overview
The Corning OptiSnap LC UPC connector is a high-performance, field-installable fiber optic connector designed for single mode 900µm fiber applications. By utilizing a mechanical splice technology, this connector eliminates the need for epoxy, polishing, or specialized curing equipment, significantly reducing installation time in the field.
Each connector features a precision ceramic ferrule and is factory-polished to a UPC finish to ensure high optical performance. These connectors are ideal for rapid, reliable fiber terminations in data centers, enterprise networks, and telecommunications environments where efficiency and consistent quality are critical.
Key Features
-
Tool-less Installation
Eliminates the requirement for epoxy or polishing, allowing for termination in less than one minute. -
Ceramic Ferrule
Ensures high durability and precise alignment for consistent signal transmission. -
Factory UPC Polish
Provides a high-quality optical finish, minimizing reflection and insertion loss. -
Single Mode Optimization
Specifically engineered for 900µm single mode fiber systems. -
Field-Proven Performance
Typical insertion loss of 0.2dB ensures reliable network connectivity. -
Compact Design
Standard LC form factor saves space in high-density patch panels and enclosures.
Applications
- Data Center connectivity
- Enterprise local area networks (LAN)
- Telecommunications fiber-to-the-x (FTTX) deployments
- Field restoration and rapid fiber repair
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | Corning |
| Model | OSNP-LCU-900-Z |
| Connector Type | LC UPC |
| Fiber Type | Single Mode |
| Fiber Diameter | 900µm |
| Typical Insertion Loss | 0.2 dB |
| Maximum Insertion Loss | 0.5 dB |
| Typical Reflectance | -55 dB |
| Housing Color | Blue |
| Quantity | 25 per pack |
Frequently Asked Questions
Does this connector require epoxy?
No, the OptiSnap system uses a mechanical splice design that requires no epoxy or polishing.
Is this compatible with multimode fiber?
No, this model is specifically designed for single mode fiber.
How long does installation take?
The average installation time for these connectors is less than one minute.
What is the ferrule material?
These connectors use a high-precision ceramic ferrule.
What is the polish type?
This connector features a UPC (Ultra Physical Contact) polish.
