Overview
The EXFO EPM-53X-PMA-22-RB is a high-power optical power meter designed for demanding fiber optic testing environments, including CATV and telecommunications networks. It provides accurate measurements for both singlemode and multimode fiber, ensuring reliable performance during installation and maintenance tasks.
Built for field use, this meter features a rugged, ergonomic design and a universal push-pull interface. With a broad power range of +26 to -50 dBm, it handles high-intensity signal sources effectively, while its intuitive interface enables quick tone recognition for efficient fiber identification.
Key Features
-
High Power Measurement Range
Supports measurements from +26 dBm to -50 dBm, suitable for high-power CATV and telco signal testing. -
Universal Connector Interface
Features an FC connector adapter (PMA-89 included) for versatile and secure physical connections. -
Tone Recognition
Integrated capability to detect modulated signals for quick and accurate fiber identification in the field. -
Reference Function
Allows for easy setting of reference levels to enable direct optical loss measurements. -
Extended Battery Life
Designed for prolonged field operation with over 300 hours of continuous use on three AA batteries. -
Ruggedized Construction
Durable build quality tailored for the rigors of outside plant and data center environments.
Applications
- CATV Network Installation
- Telecommunication Infrastructure Testing
- Enterprise and LAN Fiber Networks
- Singlemode and Multimode Loss Measurement
Package Contents
- EPM-53X-PMA-22-RB Optical Power Meter
- PMA-89 FC Connector Adapter
- Soft Pouch
- Quick Reference Sticker (5 Languages)
- Certificate of Calibration
- Certificate of Compliance
- 3 x AA Batteries
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | EXFO |
| Model | EPM-53X-PMA22RB |
| Connector Type | FC |
| Power Range | +26 to -50 dBm |
| Power Uncertainty | 5% |
| Resolution | 0.01 dB |
| Battery Life | 300+ Hours |
| Warranty | 1 Year |
Frequently Asked Questions
What is the power range of this device?
The device is calibrated for a power range of +26 to -50 dBm.
Does it support both singlemode and multimode?
Yes, it is designed to perform measurements on both singlemode and multimode fiber networks.
How is the device powered?
It operates on three AA batteries, providing over 300 hours of battery life.
Can I use this for fiber identification?
Yes, the EPM-53X includes tone recognition capabilities to assist in identifying specific fibers.
What is included in the package?
The package includes the power meter, an FC connector adapter, soft pouch, user documentation, calibration/compliance certificates, and batteries.
