Overview
The EXFO FIPT-400-SC-APC is a precision-engineered bulkhead inspection tip designed for use with EXFO fiber inspection probes. This specialized tip enables accurate visual inspection of SC/APC connector end-faces, ensuring fiber cleanliness and signal integrity within optical networks.
Designed for seamless integration with EXFO inspection systems, this adapter tip ensures consistent alignment and focus for reliable pass/fail analysis in both field and data center environments. Its robust construction supports rigorous daily use, providing technicians with the clarity needed to identify contaminants or damage on connector ferrules.
Key Features
-
Connector Compatibility
Specifically designed for SC/APC bulkhead adapters and connectors. -
Precision Alignment
Ensures accurate centering of the fiber end-face during the inspection process. -
Enhanced Visibility
Provides a clear, focused view of the ferrule surface to identify debris, scratches, or oil contamination. -
Rugged Design
Constructed for durability to withstand repeated insertion and removal cycles in the field. -
Easy Attachment
Designed for quick and secure installation onto compatible EXFO probe models. -
Standardized Inspection
Facilitates consistent inspection practices across maintenance and installation workflows.
Applications
- Fiber optic network maintenance and troubleshooting
- Data center optical patch panel inspection
- Telecommunications infrastructure installation
- Optical component manufacturing quality control
Compatibility
Fiber Inspection Probes- FIP-410B
- FIP-420B
- FIP-425B
- FIP-430B
- FIP-435B
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | EXFO |
| Model | FIPT-400-SC-APC |
| Part Number | 880X391 |
| Connector Type | SC/APC |
Frequently Asked Questions
What probe models is this tip compatible with?
This tip is compatible with EXFO FIP-410B, FIP-420B, FIP-425B, FIP-430B, and FIP-435B series inspection probes.
Is this tip suitable for UPC connectors?
No, this tip is specifically designed for SC/APC (angled physical contact) connectors. Using it with UPC connectors will not provide the correct geometry for proper inspection.
How do I install the tip?
The tip is designed to be easily attached to the head of the compatible EXFO inspection probe via a simple mounting mechanism.
Does this tip include a cleaning tool?
No, this is an inspection adapter tip only. Cleaning tools should be sourced separately.
What is the primary use of this accessory?
It is used for inspecting the connector end-face inside a bulkhead adapter for contamination or damage.
