Overview
The EXFO OHC-L Long-Reach Optical Head is a specialized accessory designed for use with the FIP-200 Connector Checker and compatible CTIP fiber inspection tips. Its primary purpose is to enable precise fiber end-face inspection in challenging, high-density environments such as optical cabinets and patch panels.
Featuring a 60mm long-reach design, this optical head allows technicians to inspect connections in recessed areas without needing to displace or disturb adjacent fiber cabling. The unit utilizes a quick-connect mechanism, allowing for rapid tip changes with a simple quarter-turn click, which streamlines the workflow for multi-point fiber testing and verification.
Key Features
-
Long-Reach Design
Features a 60mm probe length to access dense fiber patch panels and cabinets. -
Quick-Connect Mechanism
Allows for fast, efficient swapping of inspection tips with a simple quarter-turn. -
CTIP Compatibility
Designed to integrate seamlessly with standard CTIP fiber inspection tips. -
Efficient Workflow
Enables rapid testing sequences, reducing time spent during large-scale network inspections. -
Non-Disruptive Inspection
Allows for inspection in congested areas without the need to reorganize or disconnect surrounding fibers. -
Rugged Build
Engineered for consistent performance in field maintenance and installation environments.
Applications
- Fiber network installation
- Data center maintenance
- High-density cabinet troubleshooting
- Patch panel inspection
- Optical link verification
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | EXFO |
| Model | OHC-L |
| Part Number | 880X118 |
| Probe Length | 60 mm |
| Compatibility | FIP-200, CTIP Series Tips |
Frequently Asked Questions
What is the primary function of the OHC-L?
The OHC-L acts as a long-reach adapter head for the FIP-200 to inspect fiber connectors in hard-to-reach or high-density locations.
Does this include the inspection tips?
No, the inspection tips are sold separately. It is compatible with the CTIP series of inspection tips.
How is the tip attached to the optical head?
It uses a quick-connect system that requires only a quarter-turn to lock into place.
Can I use this with other inspection probes?
This model is specifically designed for the EXFO FIP-200 Connector Checker.
What is the length of this optical head?
The probe reach is 60mm.
