EXFO PM-MAX-2X-VFL VFL and Power Meter Module for MAX-715B

Overview

The EXFO PM-MAX-2X-VFL is a dual-function field module designed to expand the testing capabilities of the EXFO MAX-715B Last-Mile OTDR. Integrating a Visual Fault Locator (VFL) and an optical power meter with a GeX detector, this module allows technicians to perform essential fiber characterization tasks, including continuity checking, fault identification, and loss measurement.

Constructed for demanding field environments, this module integrates directly into the OTDR platform, ensuring a streamlined workflow for network engineers and fiber technicians. It is equipped with an SC connector adapter to support common connection standards in FTTx and last-mile network deployments.

Key Features

• Dual-Functionality
  Combines a visual fault locator and an optical power meter in a single module to reduce the number of tools required for field testing.
• GeX Detector
  High-sensitivity power meter detector optimized for accurate power measurement across a wide dynamic range.
• Integrated Design
  Engineered specifically for seamless compatibility with the EXFO MAX-715B OTDR series.
• Visual Fault Localization
  Features a visible light source to quickly identify macro-bends, breaks, and damaged connectors.
• SC Connector Compatibility
  Includes a standard SC adapter to facilitate direct connections to common fiber infrastructure.
• Field-Ready Construction
  Designed for durable, portable use during installation and maintenance of fiber optic networks.

Applications

• FTTx network construction and troubleshooting
• Last-mile fiber link characterization
• Fiber optic cable continuity verification
• Connector and splice inspection
• General power level measurement

Technical Specifications

Frequently Asked Questions

What is the primary function of this module?
The PM-MAX-2X-VFL provides both a Visual Fault Locator for tracing fiber and an optical power meter for measuring signal strength.

Is this module compatible with other OTDR models?
This specific module is designed for use with the EXFO MAX-715B Last-Mile OTDR.

What connector type does it support?
It comes equipped with an SC connector adapter.

What does the GeX detector signify?
GeX refers to a high-sensitivity germanium detector optimized for a broader dynamic range compared to standard detectors.

Is the power meter calibrated for specific wavelengths?
Please refer to the included manufacturer datasheet for complete calibration and wavelength coverage details.
