Overview
The EXFO RAC-21-110 is a specialized bulkhead connector adapter designed for high-density fiber optic network environments. It serves as a critical interface accessory for the EXFO FIP-500 fiber inspection scope, enabling efficient and accurate assessment of connector end-faces.
This adapter is engineered to support the simultaneous inspection of both ferrules found in CS duplex connectors. Its robust construction ensures precise alignment, which is essential for maintaining signal integrity and clear visual inspection in dense cabling configurations.
Key Features
-
Duplex Support
Facilitates simultaneous inspection of two ferrules in a single duplex connector housing. -
High-Density Compatibility
Specifically designed for use in environments where space and connector density are maximized. -
Precision Alignment
Ensures the ferrules are perfectly positioned for high-resolution imaging during inspection. -
Inspection Scope Integration
Optimized for seamless connectivity with the EXFO FIP-500 fiber inspection system. -
Quick-Connect Interface
Allows for rapid switching of adapter tips to accommodate different connector types. -
Durable Build
Constructed to withstand regular use in both field and data center environments.
Applications
- Data center fiber infrastructure inspection
- High-density optical network maintenance
- Verification of CS duplex connector end-face cleanliness
- Fiber optic link certification
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | EXFO |
| Model | RAC-21-110 |
| Connector Type | CS/UPC Duplex |
| Compatibility | EXFO FIP-500 |
Frequently Asked Questions
What is the primary function of the RAC-21-110?
It is an adapter tip for the EXFO FIP-500 inspection scope used to inspect CS duplex bulkhead connectors.
Does this adapter inspect both fibers at once?
Yes, it is designed to inspect both ferrules of a duplex connector simultaneously.
Is this compatible with other EXFO inspection scopes?
This adapter is designed for the FIP-500 series.
What is the connector polish type?
It supports the UPC polish type.
Are other tips required for this setup?
Yes, this adapter typically requires a compatible SmarTip (such as the STIP-CS-DF-U, sold separately) to complete the inspection assembly.
