Overview
The 1x16 Optical Splitter in an OSP (Outside Plant) package is engineered for reliable signal distribution in harsh environmental conditions. By integrating high-performance PLC technology into a ruggedized cassette, this assembly ensures consistent optical performance while maintaining superior protection for sensitive fiber components.
Designed for rapid deployment, this splitter is ideal for fiber-to-the-x (FTTX) architectures where space in cabinets and enclosures is at a premium. The compact design and integrated jacketed leads allow for seamless integration into existing OSP infrastructure, minimizing installation time and reducing the risk of damage to the fiber during routing.
Key Features
-
Ruggedized OSP Housing
Features a durable cassette enclosure that protects internal components from moisture, dust, and physical impact in outdoor environments. -
High-Density Design
Compact 100mm x 80mm x 10mm footprint maximizes available real estate in congested cabinets and enclosures. -
LC/APC Connectivity
Provides low-reflectance, high-precision connections to support high-speed signal integrity. -
Jacketed Lead Protection
Equipped with 2mm jacketed leads to offer increased mechanical robustness during cable management and routing. -
Wide Wavelength Operation
Supports operation across a broad range from 1260nm to 1650nm, ensuring versatility across various network standards. -
Streamlined Installation
Factory-terminated and tested design enables quick, plug-and-play deployment for field technicians.
Applications
- FTTX and FTTH network deployments
- Outside plant cabinet and enclosure integration
- Passive Optical Networks (PON)
- Data center and enterprise fiber distribution
Technical Specifications
| Specification | Value |
|---|---|
| Part Number | Z1PLCM116OSP20A2LA1.5 |
| Split Ratio | 1x16 |
| Connector Type | LC/APC |
| Operating Wavelength | 1260nm - 1650nm |
| Lead Jacket Diameter | 2mm |
| Package Dimensions | 100mm L x 80mm W x 10mm H |
Frequently Asked Questions
What is the primary advantage of the OSP package?
The OSP cassette provides an environmentally hardened enclosure that protects the splitter from external stressors, making it suitable for field installations.
Are these splitters suitable for high-density environments?
Yes, the 100mm x 80mm x 10mm dimensions are optimized for saving space in crowded fiber cabinets and enclosures.
What wavelength range does this device support?
It supports a wide operating range from 1260nm to 1650nm.
What connector type does this assembly use?
This model is equipped with LC/APC connectors for low back-reflection performance.
What does the OSP package include?
The package includes the PLC splitter in a protected cassette with 2mm jacketed leads ready for termination.
