Overview
This optical splitter is designed for use in Outside Plant (OSP) environments, providing a robust solution for fiber distribution and management. Housed in a durable OSP cassette, this unit offers enhanced fiber protection and is optimized for rapid installation within hardened environments, such as cabinets and enclosures.
The device features a 1x32 split ratio and is equipped with LC/APC connectors for high-performance signal integrity with low back-reflection. The unit includes 1.5-meter leads with a 2mm jacket for added physical resilience during routing and management in dense network infrastructures.
Key Features
-
OSP Hardened Design
Cassette housing protects sensitive fiber components from environmental hazards during outdoor deployment. -
High Split Ratio
1x32 configuration allows for efficient signal distribution in PON architectures. -
LC/APC Connectivity
Angled Physical Contact connectors minimize back-reflection for improved signal quality in sensitive systems. -
Optimized Form Factor
Compact 100mm x 80mm x 10mm dimensions maximize available space in cabinets and pedestals. -
Durable Cabling
2mm jacketed leads provide protection during cable routing and installation. -
Broad Wavelength Range
Supports operation across the 1260nm to 1650nm range for standard fiber network compatibility.
Applications
- FTTH (Fiber to the Home) networks
- PON (Passive Optical Networks)
- Outside plant cabinet distribution
- Outdoor terminal enclosures
- Central office fiber management
Technical Specifications
| Specification | Value |
|---|---|
| Part Number | Z1PLCM132OSP20A2LA1.5 |
| Split Ratio | 1x32 |
| Connector Type | LC/APC |
| Operating Wavelength | 1260nm - 1650nm |
| Lead Length | 1.5 meters |
| Jacket Diameter | 2mm |
| Dimensions (LxWxH) | 100mm x 80mm x 10mm |
Frequently Asked Questions
What does OSP package mean?
OSP refers to Outside Plant, meaning the splitter is housed in a ruggedized, weather-resistant cassette designed for use in outdoor enclosures or distribution cabinets.
Are the connectors pre-installed?
Yes, the unit comes pre-terminated with LC/APC connectors.
What is the primary benefit of the APC polish?
The Angled Physical Contact (APC) polish significantly reduces return loss by reflecting light into the cladding rather than back toward the source.
Can this splitter be used for other split ratios?
This specific SKU is a 1x32 configuration. The product series supports other configurations including 1x4, 1x8, 1x16, 1x64, 2x16, and 2x32.
What is the cable length?
This unit includes 1.5-meter leads.
