Overview
The Optical Splitter in an OSP (Outside Plant) cassette is designed to address the environmental challenges of field deployments. This unit provides robust fiber protection, facilitating quick and secure installation in hardened environments while maximizing valuable space within distribution cabinets and enclosures.
Engineered for reliability in outside plant applications, this splitter utilizes advanced planar lightwave circuit technology to provide stable optical performance. The ruggedized package ensures consistent signal splitting, making it an essential component for FTTX network deployments.
Key Features
-
OSP Hardened Package
Designed for outside plant conditions, ensuring protection in harsh environments. -
Planar Lightwave Circuit Technology
Provides stable and uniform optical splitting performance across all output ports. -
LC/APC Connectivity
Features factory-terminated LC/APC connectors for low back-reflection and compatibility with standard hardware. -
Space-Efficient Design
Compact cassette form factor minimizes the footprint in cabinets and enclosures. -
Jacketed Leads
2mm jacketed leads provide extra physical protection for the input and output fibers. -
Wide Operating Wavelength
Supports a broad wavelength range of 1260nm to 1650nm.
Applications
- Fiber-to-the-X (FTTX) deployments
- Passive Optical Networks (PON)
- Outside plant cabinet installations
- Central office distribution
Technical Specifications
| Specification | Value |
|---|---|
| Split Ratio | 1x4 |
| Operating Wavelength | 1260nm - 1650nm |
| Connector Type | LC/APC |
| Lead Type | 2mm Jacketed |
| Package Dimensions | 100mm L x 80mm W x 10mm H |
Frequently Asked Questions
What does OSP package mean?
It refers to an Outside Plant package designed to withstand environmental factors, typically used in cabinets or pedestals.
What kind of connectors does this use?
This unit comes with LC/APC connectors, which feature an angled physical contact for reduced return loss.
Is the cable jacketed?
Yes, the leads are protected by a 2mm jacket.
What is the operating wavelength range?
The device operates between 1260nm and 1650nm.
Can this be used for FTTX?
Yes, it is commonly used in FTTX networks for signal distribution.
