Overview
The Optical Splitter in an OSP cassette is designed to address the unique challenges of outside plant environments. It provides enhanced fiber protection, enabling rapid deployment in hardened network locations while maximizing cabinet and enclosure space.
This high-density splitter module is engineered for reliability, featuring 2x32 configuration with robust 2mm jacketed leads. Its specialized OSP package design ensures superior performance and durability, making it an ideal choice for FTTX, PON, and other demanding fiber distribution applications requiring organized, secure, and space-efficient connectivity.
Key Features
-
OSP Hardened Design
Optimized for environmental protection, ensuring long-term network stability in outdoor plant settings. -
High-Density 2x32 Split Ratio
Allows for efficient splitting of optical signals in a compact, manageable footprint. -
LC/APC Connectorization
Provides low-loss, high-return-loss connections suitable for sensitive video and data transmissions. -
2mm Jacketed Leads
Robust cable protection that resists mechanical stress during installation and routing. -
Space-Efficient Form Factor
Compact OSP package size maximizes density within existing cabinets and fiber enclosures. -
Broad Operating Wavelength
Supports a wide 1260nm to 1650nm range for versatile use across common fiber optic network standards.
Applications
- FTTX / FTTH Deployments
- Passive Optical Networks (PON)
- Central Office and Local Loop Distribution
- Outdoor Fiber Distribution Cabinets
- Hardened Environment Connectivity
Technical Specifications
| Specification | Value |
|---|---|
| Split Configuration | 2x32 |
| Connector Type | LC/APC |
| Operating Wavelength | 1260nm - 1650nm |
| Lead Diameter | 2mm |
| Package Dimensions | 100mm L x 80mm W x 10mm H |
Frequently Asked Questions
What does OSP refer to?
OSP stands for Outside Plant, meaning this equipment is specifically built for durability in outdoor or harsh environment cabinets.
What connector type is included?
This model is equipped with LC/APC connectors, which utilize an angled physical contact for improved back-reflection performance.
Can this be used for FTTX?
Yes, it is designed for FTTX distribution where space and environmental protection are required.
What is the wavelength range?
The splitter is designed for operation between 1260nm and 1650nm, covering typical singlemode operational bands.
Is the 2mm jacket standard?
Yes, it is a robust jacketing for the leads, providing mechanical protection during field installation.
