Optical Splitter LGX 1x4 with LC/APC Connectors and 2m Jacketed Leads

Overview

The Optical Splitter in an LGX package is designed for seamless integration into standard LGX-style rack mount or wall mount enclosures. This module features a 1x4 split ratio, providing efficient signal distribution for fiber optic networks. It is equipped with 2-meter long, 1.6mm jacketed leads to facilitate easy routing within fiber management hardware.

This single-width module is built for deployment in telecommunications and data center environments, supporting reliable optical signal splitting across a wide range of operational wavelengths. Its standardized LGX footprint ensures compatibility with a broad array of existing optical enclosures and termination points.

Key Features

• Standardized LGX Footprint
  Designed for universal compatibility with 1HU (0.875" high) rack and wall mount enclosures.
• 1x4 Split Configuration
  Provides precise power splitting for FTTH and network distribution applications.
• LC/APC Connectivity
  Features industry-standard angled physical contact connectors to minimize back-reflection.
• Integrated 2m Leads
  Includes 2-meter long, 1.6mm jacketed leads for flexible routing and installation.
• Broad Wavelength Range
  Supports operation across 1260nm to 1650nm, ensuring versatile network performance.
• Robust Housing
  Engineered to protect the internal splitter components within high-density environments.

Applications

• FTTH (Fiber to the Home) deployments
• Central office and data center fiber management
• Passive Optical Networks (PON)
• Telecommunications signal distribution

Technical Specifications

Frequently Asked Questions

Is this splitter compatible with standard LGX racks?
Yes, this module is designed to fit any standard LGX-style rack or wall mount enclosure.

What is the lead length included with this module?
The module comes with 2-meter long leads.

What type of connectors are used?
The unit uses LC/APC connectors.

What is the operating wavelength range?
The splitter supports operations from 1260nm to 1650nm.

Does this module occupy a single slot?
Yes, it is a single-width module in the LGX footprint.
