Optical Splitter LGX LC/APC Connectors 1x32 Dual 2m Long 1.6mm Jacketed Leads

Overview

The Optical Splitter in an LGX package is designed for seamless integration into standard LGX-style rack mount or wall mount enclosures. This module facilitates efficient optical signal distribution for fiber-to-the-x (FTTX) architectures and high-density network environments.

Constructed as a double-wide module, it features 2-meter long, 1.6mm jacketed leads to provide sufficient slack for routing and termination. The unit is optimized for stable performance across a wide operating wavelength range, ensuring compatibility with standard singlemode transmission systems.

Key Features

• LGX Footprint Compatibility
  Standardized form factor allows for simple installation in existing rack or wall-mounted enclosures.
• 1x32 Split Ratio
  Supports high-density signal distribution, ideal for passive optical network applications.
• LC/APC Connectors
  Utilizes angled physical contact connectors to minimize back-reflection and optimize signal integrity.
• Long Jacketed Leads
  Includes 2-meter, 1.6mm jacketed pigtails for easier fiber management and patching.
• Double-Wide Module Design
  Configured as a double-wide unit to balance physical size with port density.
• Broad Operating Wavelength
  Supports signal transmission across the 1260nm to 1650nm spectrum.

Applications

• Passive Optical Networks (PON)
• FTTH/FTTX Deployment
• Data Center Fiber Management
• High-Density Signal Distribution

Technical Specifications

Frequently Asked Questions

What rack enclosures are compatible with this splitter?
This module uses the standard LGX footprint and is compatible with any LGX-style rack mount or wall mount enclosure.

What is the purpose of the APC connector?
The LC/APC (Angled Physical Contact) connector is used to reduce back-reflection, which is critical for maintaining signal quality in sensitive fiber optic networks.

Can this be used in an outdoor environment?
This product is designed for installation in standard rack or wall mount enclosures, which are typically located indoors or within protected environmental cabinets.

What does the 2m lead length provide?
The 2-meter pigtails provide ample length for routing the fibers from the splitter module to the adapter plates or active equipment within the enclosure.

Does this splitter support wavelengths outside the specified range?
Performance is specified for the 1260nm to 1650nm range; operation outside this range is not guaranteed.
