Optical Splitter LGX SC/APC 1x4 2m Long 1.6mm Jacketed Leads

Overview

The Optical Splitter in an LGX package is designed for seamless integration into standard LGX-style rack or wall-mount enclosures. This module features a 1x4 split ratio and comes pre-configured with 2-meter long, 1.6mm jacketed leads, allowing for organized and efficient fiber routing within data centers, central offices, and FTTX infrastructure.

Engineered for consistent optical signal distribution, this splitter utilizes advanced planar technology to ensure reliable performance across a wide wavelength range. The LGX form factor simplifies deployment, allowing technicians to quickly mount the module into existing high-density fiber management systems.

Key Features

• LGX Compatibility
  Designed to fit standard LGX rack and wall mount enclosures for easy installation and modular scaling.
• Standardized Split Ratio
  Features a 1x4 split configuration for precise signal distribution in passive optical networks.
• Jacketed Fiber Leads
  Includes 2-meter, 1.6mm jacketed leads for enhanced protection and manageability of fibers during routing.
• Wide Operating Wavelength
  Supports a broad wavelength range from 1260nm to 1650nm, suitable for diverse network applications.
• High-Precision Connectors
  Equipped with SC/APC connectors to ensure minimal signal reflection and low insertion loss.
• Modular Design
  Occupies a single-width LGX slot, optimizing space within fiber management hardware.

Applications

• FTTX / FTTH Networks
• Passive Optical Networks (PON)
• Data Center Fiber Management
• Central Office Distribution
• CATV Networks

Technical Specifications

Frequently Asked Questions

Is this splitter compatible with any rack mount enclosure?
The module is designed for the industry-standard LGX footprint. It will fit any enclosure that supports the LGX modular system.

Can I use this for both indoor and outdoor deployments?
This module is typically intended for indoor enclosure environments. For outdoor use, it should be housed within an OSP-rated closure.

What does SC/APC mean?
It indicates the connector type is SC (Standard Connector) with an APC (Angled Physical Contact) polish, which is used to minimize back-reflection.

Are other split ratios available?
Yes, this series is available in 1x2, 1x4, 1x8, 1x16, and 1x32 configurations.

Does the module come pre-loaded in a housing?
The splitter is packaged as a module designed to be installed into a larger rack or wall-mount housing.
