Overview
The Optical Splitter Module features Planar Lightwave Circuit (PLC) technology housed in a compact, LGX-compatible package. Designed for efficiency and ease of integration, this module provides a reliable 1x4 split ratio for optical networks. It is suitable for installation in various fiber management systems, including standard LGX-style rack mount or wall mount enclosures.
Equipped with high-precision LC/APC connector adapters, this splitter ensures low-loss signal distribution across an operating wavelength range of 1260nm to 1650nm. Its robust, modular design facilitates quick deployment in data centers, FTTX installations, and enterprise networking environments.
Key Features
-
PLC Technology
Utilizes planar lightwave circuit technology for consistent, uniform signal splitting across all output ports. -
Standard LGX Footprint
Designed to fit industry-standard LGX rack or wall mount enclosures for easy system integration. -
LC/APC Connectivity
Features high-quality LC/APC adapters to ensure low back-reflection and optimal signal integrity. -
Broad Wavelength Support
Supports operation across the 1260nm to 1650nm range, making it compatible with various network standards. -
Compact 1RU Design
The low-profile 0.875-inch height allows for high-density fiber management in tight rack spaces. -
1x4 Split Ratio
Provides a precise 1-to-4 optical signal distribution, ideal for passive optical network architecture.
Applications
- FTTX (Fiber-to-the-x) Networks
- Passive Optical Networks (PON)
- Enterprise LAN/WAN Infrastructure
- Data Center Fiber Management
Technical Specifications
| Specification | Value |
|---|---|
| Part Number | Z1PLM141SLLA |
| Module Type | LGX Footprint (Short) |
| Split Ratio | 1x4 |
| Connector Type | LC/APC |
| Operating Wavelength | 1260nm - 1650nm |
| Physical Form Factor | 1HU (0.875" high) |
Frequently Asked Questions
What does the LGX footprint mean?
The LGX footprint is a standardized mounting design used in fiber optic enclosures, ensuring the module can be easily snapped into place without proprietary hardware.
Is this module compatible with existing SC/APC patch panels?
This specific part is configured with LC/APC adapters. Please verify your patch panel connector type or consider our SC/APC variants if needed.
What is the primary benefit of PLC technology?
PLC (Planar Lightwave Circuit) technology provides superior uniformity and stability over wider wavelength ranges compared to older FBT-based splitters.
Can this be mounted in a standard rack?
Yes, this module is designed for use in standard LGX-style rack or wall mount enclosures.
Does this module include fiber optic patch cables?
No, patch cables are typically purchased separately based on your specific routing needs.
