Overview
The Optical Splitter Module is a professional-grade PLC (Planar Lightwave Circuit) component designed for high-density fiber management. Engineered for versatility, this 1x8 splitter is housed in a compact LGX-style module that facilitates seamless integration into standard rack or wall-mount enclosures.
This module features LC/APC connector adapters, ensuring precise alignment and low insertion loss for sensitive network applications. It is optimized for operation within the standard telecommunications wavelength range of 1260nm to 1650nm, making it a suitable choice for FTTX, passive optical networks, and general fiber infrastructure deployments.
Key Features
-
Standard LGX Footprint
Compatible with industry-standard LGX rack and wall-mount enclosures for easy installation and modular scalability. -
PLC Technology
Utilizes Planar Lightwave Circuit technology for uniform light distribution and high stability across all output ports. -
LC/APC Connectivity
Equipped with LC/APC adapters to minimize back-reflections and ensure high return loss in demanding networks. -
1x8 Split Ratio
Provides efficient signal distribution from a single input to eight output channels. -
Broad Wavelength Range
Supports operation from 1260nm to 1650nm, ensuring compatibility with a wide variety of transmission equipment. -
Compact Design
The short, 1RU-compatible package saves valuable space in congested fiber cabinets.
Applications
- FTTX (Fiber to the X) networks
- Passive Optical Networks (PON)
- CATV and broadcast signal distribution
- Data center fiber cross-connects
- General telecommunications infrastructure
Technical Specifications
| Specification | Value |
|---|---|
| Part Number | Z1PLM181SLLA |
| Module Type | PLC Splitter, LGX Package |
| Split Ratio | 1x8 |
| Connector Adapters | LC/APC |
| Operating Wavelength | 1260nm - 1650nm |
| Form Factor | Short LGX |
| Rack Compatibility | 1RU / 1HU |
Frequently Asked Questions
Is this module compatible with existing LGX enclosures?
Yes, it is designed to fit standard LGX-style rack and wall-mount enclosures.
What is the operating wavelength range?
The module supports wavelengths from 1260nm to 1650nm.
Are other split ratios available?
This model is configured for 1x8, though other split ratios are supported in the same series.
Does this unit come with connectors installed?
Yes, it includes integrated LC/APC connector adapters.
Can this be mounted in a 1RU rack space?
Yes, it is designed for both LGX module housings and 1RU rack-mount integration.
