Overview
The Optical Splitter in an OSP (Outside Plant) cassette is designed for robust performance in demanding field environments. It features a hardened enclosure that protects internal components, ensuring long-term stability and consistent signal distribution in outdoor applications.
This 1x32 splitter is pre-terminated with SC/APC connectors and includes 2mm jacketed leads, allowing for rapid deployment and easy integration into existing cabinets or closure systems. The compact cassette design optimizes internal space while providing the necessary fiber management for reliable network connectivity.
Key Features
-
OSP Hardened Design
Features a specialized cassette package suitable for outdoor cabinet and enclosure environments. -
High-Density 1x32 Split Ratio
Provides efficient signal distribution to up to 32 endpoints from a single input fiber. -
SC/APC Connectivity
Comes pre-terminated with industry-standard SC/APC connectors for low back-reflection requirements. -
2mm Jacketed Leads
Includes protective 2mm jacketing to ensure cable durability during installation and routing. -
Wide Operating Wavelength
Supports operation across the 1260nm to 1650nm range for broad network compatibility. -
Compact Form Factor
Optimized dimensions (100mm x 80mm x 10mm) to maximize space efficiency in standard OSP cabinets.
Applications
- FTTH (Fiber to the Home) networks
- Outside plant cabinet installations
- PON (Passive Optical Network) distribution
- Hardened outdoor enclosures
Technical Specifications
| Specification | Value |
|---|---|
| Split Ratio | 1x32 |
| Connector Type | SC/APC |
| Lead Jacket Diameter | 2mm |
| Lead Length | 1.5m |
| Operating Wavelength | 1260nm - 1650nm |
| Package Dimensions | 100mm L x 80mm W x 10mm H |
Frequently Asked Questions
What is the primary environment for this splitter?
This splitter is designed for Outside Plant (OSP) environments, specifically for use within protective cabinets and enclosures.
Are these connectors pre-installed?
Yes, the unit comes pre-terminated with SC/APC connectors on all leads for quick installation.
Can this be used in standard indoor racks?
While designed for OSP cabinets, the physical footprint is similar to LGX-style components, though it is specifically optimized for hardened exterior enclosures.
What is the purpose of the 2mm jacketing?
The 2mm jacket provides physical protection to the fiber leads during the installation process in crowded cabinets.
Does this splitter support wavelength-division multiplexing?
It operates within the 1260nm to 1650nm range, covering standard telecommunication operating bands.
