Overview
The Orion Series Enclosure Splice Tray is a specialized internal component designed for the efficient organization and protection of fiber optic splices. It is engineered for use within the Orion series enclosure system, providing a secure platform to manage fiber slack and splice points in both pole and wall-mount configurations.
This splice tray is built to meet the rigorous demands of industrial data center and telecommunications deployments. Its design ensures proper bend radius management, maintaining signal integrity and protecting delicate fiber connections from physical stress in various mounting environments.
Key Features
-
Modular Design
Specifically configured for the Orion series enclosure to ensure a precise, drop-in fit. -
Bend Radius Control
Features built-in radius guides to prevent signal loss caused by over-bending fibers. -
Organized Splicing
Provides clear, designated areas for securing splice protection sleeves and managing fiber slack. -
Robust Construction
Constructed from durable materials to maintain structural integrity in standard operating environments. -
Versatile Mounting
Compatible with both wall and pole mounting applications to suit diverse installation requirements. -
Simplified Installation
Designed for quick and straightforward mounting within the enclosure chassis, reducing field installation time.
Applications
- Telecommunications Central Offices
- Data Center Fiber Management
- FTTX Distribution Hubs
- Wall-mount and Pole-mount Fiber Enclosures
Technical Specifications
| Specification | Value |
|---|---|
| Model | Orion Series |
| Part Number | Z1-ORI16T |
| Product Type | Splice Tray |
| Mounting Compatibility | Pole/Wall Mount |
Frequently Asked Questions
Is this tray compatible with other enclosure brands?
This tray is specifically designed for the Orion Series enclosure and may not be compatible with other systems.
Does this include the external enclosure box?
No, this item is the splice tray only.
Can this be mounted directly to a wall?
The tray is designed to mount within the Orion series enclosure, which is then mounted to the wall or pole.
What is the primary function of this tray?
The primary function is to store and protect fiber optic splices while maintaining correct fiber bend radii.
Is this suitable for outdoor environments?
While the tray is contained within the enclosure, the system is designed for standard deployment environments; consult your enclosure specifications for total environmental ratings.
